Periodic Tables referencing the text string "René", listed by date:

Gibbes' Synoptical Periodic Table

From page 127 of The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896). The full text (scanned) is available from archive.org.

Venable writes:

Thanks to René for the tip!

Concentric Ring Arrangement of Wiik

From page 133 of The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896). The full text (scanned) is available from archive.org.

Venable writes:

Thanks to René for the tip!

Waechter's Numerical Regularities

From page 136 of The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896). The full text (scanned) is available from archive.org.

Venable writes:

Thanks to René for the tip!

Bayley's Attempt

From page 158 of The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896). The full text (scanned) is available from archive.org.

Venable writes about Bayley:

Thanks to René for the tip!

Carnelley & The Periodic Law

From page 172 of The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896). The full text (scanned) is available from archive.org.

Venable writes:

Thanks to René for the tip!

von Richter's Periodic System of the Elements

From page 244 of A Text-book of Inorganic Chemistry by Victor von Richter, Published by Blakiston (US ed. in English, 1885). The full text (scanned) is available from archive.org. The first edition was published in 1874 in German. von Richter was was from the Baltic region, in the the Russian empire at the time.

von Richter's work is almost certainly the first chemistry textbook based on the periodic system. Many (indeed most) modern Inorganic Chemistry texts follow this format, but NOT the Chemogenesis web book!

von Richter, writes:

Thanks to René for the tip!

Shepard's Natural Classification

Shepard's Natural Classification of the Elements, a spiral formulation with instructions for turning it into a three-dimensional table. From: Elements of Inorganic Chemistry, Descriptive and Qualitative (pp221), by J. H. Shepard, (1886), Boston MA, pub. D. C. Heath

René Vernon writes:

Note the instructions along the side, to turn the table into a tube (spiral form) and the 19 spaces from La to eka-Ce. Here, Yb needs to be moved back one column into group II, so as to leave room for Lu under La. Then eka-Ce becomes Hf. This results in La + 15 lanthanoids.

The accompanying text says:

"Elements of most distinct basic character are found towards the left; non-metals predominate in the upper and middle parts of Groups V., VI., and VII. ; while the lower part of the table is marked by the more indifferent elements.

"A double spiral will be traced beyond Si (beginning with P and V respectively) and distinguished by heavy-face and light-face type.

"The harmony of nature here exhibited is most impressive. Is it possible that the so-called elements are really compounds? Did the various 'elements' of the earth and sun once exist as hydrogen, when our solar system was a nebula? And will modern chemists ever revive the famed problem of the alchemists, and seek to turn the base metals into gold? Far more precious than gold is the search for truth; and the more we learn of science, the broader becomes our conception of what we know in part, and the deeper should be our reverence for the infinite thought of the Creator."

Stoney's Spiral Periodic Table

In the Proceedings of the Royal Society of London, Series A, Containing Papers of a Mathematical and Physical Character, Volume 85, Issue 580, Aug 1911, p. 472, there is an article On Dr. Johnstone Stoney's Logarithmic Law of Atomic Weights, by Lord Rayleigh (who co-discovered argon in 1894), who writes :

"In the year 1888, Dr. G. Johnstone Stoney communicated to the Society a memoir with title nearly as above, which, however, was not published in full. At the request of the author, who attaches great importance to the memoir, I have recently, by permission of the Council, consulted the original manuscript in the archives of the Society, and I propose to give some extracts, accompanied by a few remarks. The author commenced by plotting the atomic weights of the elements taken as ordinates against a series of natural numbers as abscissæ. But a curve traced through the points thus determined was found to be 'one which has not been studied by mathematicians.

"This sudden transition may have some connection with the fact that no elements have been found on sesqui-radius 16, although the investigation in § 3 shows that the values of m corresponding to the stations on sesqui-radius 16 cannot be dispensed with.

"The vacant places here pointed out are now occupied by the since discovered inert gases. The anticipation is certainly a remarkable one, and it goes far to justify the high claims made for the diagram, as representing in a telling form many of the leading facts of chemistry."

Comment from Mark Leach:

"Notice how the electronegative elements are positioned top right & bottom right and the electropositive elements top left & bottom right."

René Vernon writes:

"Stoney has another article in the September 1902 edition of the The London, Edinburgh and Dublin Philosophical Magazine and Journal of Science, called Law of Atomic Weights, pp. 411–415. At the back of the journal is an updated fold-out version of Stoney’s table, image attached.

• Ar, Kr and Xe fit on the spiral, and on spoke 16.
• Neon fits on the spiral but is instead on spoke 8.
• Helium is on spoke 18 but is not on the spiral.
• The circle in the middle represents H (p. 414).

"On the page after the updated spiral, there looks to be some printed content, but it is hidden by what looks to be a folded over page."

Thanks to René for the tip!

Wendt's Generation-Tree of the Elements

From page 244 of The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896). The full text (scanned) is available from archive.org.

Venable writes:

Thanks to René for the tip!

Rang's Periodic Arrangement of The Elements

P.J.F. Rang's The Periodic Arrangement of the Elements, Chemical News, vol. 67, p. 178 (1893)

Observing that that Rang's table has four 'groups': A, B, C & D, René Vernon writes:

1. Group A contains the strongest positive elements; group D the strongest negative elements. At such an early date, it's odd to see groups 1 to 3 categorised together.
2. Group B are the elements with high melting points; "they are all remarkable for their molecular combinations" (presuamably, a reference to multiple oxidation states). At one side of group B are the "anhydro-combinations", probably referring to the simple chemistry of Ti, Zr, [Hf] Nb and Ta being dominated by insoluble oxides. At the other side are the "amin, carbonyl, and cyanogen combination", probably a reference to the group VIII carbonyls, as metal carbonyls had only just been discovered. Ni is shown after Fe, rather than Co.
3. Group C includes the "heavy metals that have low melting points"; an early reference to frontier or post-transition metals, as a category.
4. Rang says: ...if groups A and D be split up vertically in respectively three and two parts, the table presents seven vertical groups, and horizontally seven more or less complete series. Each group in each of the series 2 and 3 are represent by one element... The octave appears both horizontally and vertically in the table.
5. Rang's reference to Di as representing all the triads between Ba and Ta kind of works since Hf would go under Zr, and that would leave 15 Ln or five sets of three. Thus, something like this:

   Gd occupies the central position among the Ln. This arrangement won't fit however unless Rang envisaged all 15 Ln occupying the position under Y.
6. The location of H over | Ga | In | Tl, appears strange... but the electronegativity of H (2.2) is closer to B (2.04) than it is to C (2.55).

From Quam & Quam's 1934 review paper.pdf

Nechaev's Truncated Cones

René Vernon (who found this formulation) writes:

This weird and wonderful table appears in Teleshov & Teleshova (2019, p. 230). It is attributed by them to Nechaev (1893) and is apparently discussed by Ipatiev (1904):

"... We would also like to mention one more version of the periodic table, namely the one offered by V. Ipatiev. Ipatiev's version was one of the first to have been applied in a school textbook, and is also concise and accompanied by a detailed methodological commentary. More specifically, Ipatiev is important in directing our attention to the fact that an essential feature common to all elements should be chosen if the elements are to be systematized. Furthermore, Ipatiev also offered another crucial insight in arguing that this selected feature must satisfy certain conditions, namely: 1) it must be measurable, 2) it must be common to all elements and 3) it must be paramount, i.e. that all the remaining properties of the elements must depend on it [Ipatiev]."

• The caption accompanying the table is: "Scanning of the projection of rotational bodies in the form of truncated cones as used in Nechaev's spatial construction of the periodic system, 1893."
• Looking at the table it seems to anticipate, after a fashion, the double periodicity noticed by later authors.
• Alternatively, if turned on its side, it would be just five columns wide.
• Between Ce (ignoring Di) and Yb, there are spaces for 12 missing elements, which is one too many.
• Pulling Yb back by one position would have done the trick.

References:

Ipat'ev, V. & Sapozhnikov, A. (1904). Kratkij kurs himii po programme voennyh uchilishh [A concise course in chemistry for military academies]. Sankt-Peterburg: tip. V. Demakova.

Nechaev N. P. (1893). Graficheskoe postroenie periodicheskoj sistemy jelementov Mendeleeva. Sposob Nechaeva [Graphic construction of Mendeleev's periodic system of elements. Nechaev's way]. Moskva: tip. Je. Lissnera i Ju. Romana

Teleshov S, Teleshova E.: The international year of the periodic table: An overview of events before and after the creation of the periodic table. In V Lamanauskas (ed.).: Science and technology Education: Challenges and possible solutions. Proceedings of the 3rd International Baltic Symposium on Science and Technology Education, BalticSTE2019, Šiauliai, 17-20 June, 2019. pp. 227-232, (2019)

Ramsay's Elements Arranged in the Periodic System

From The Gases of the Atmosphere, The History of Their Discovery by William Ramsay (and from the Gutenberg Project.)

The author writes pp 220-221:

"In 1863 Mr. John Newlands pointed out in a letter to the Chemical News that if the elements be arranged in the order of their atomic weights in a tabular form, they fall naturally into such groups that elements similar to each other in chemical behaviour occur in the same columns. This idea was elaborated farther in 1869 by Professor Mendeléeff of St. Petersburg and by the late Professor Lothar Meyer, and the table may be made to assume the subjoined form (the atomic weights are given with only approximate accuracy):—"

Thanks to René for the tip!

Venable's The Development of The Periodic Law

The Development of the Periodic Law by Venable, Francis Preston (1856-1934), Easton, Pa. Chemical Pub. Co (1896).

The full text (scanned) is available from archive.org.

Thanks to René for the tip!

Grouping of The Elements to Illustrate Refractivity

From C. Cuthbertson & E. Parr Metcalfe, Part III On The Refractive Indices of Gaseous Potassium, Zinc, Mercury, Arsenic Selenium and Tellurium, Phil. Trans. A: Mathematical & Physical Sciences, vol 207, pp135–148, 1907.

René Vernon writes:

"A curious periodic table which runs from group 12 on the left to group 13 on the right (see below). It seems to have done that way to bring out the pattern in multiples of refractivities i.e. x½ x 4 x 6 x10. The border around the elements in groups 15 to K-Rb-Cs in group 1 denotes this relatively strong regularity among the refractivity values. The L for iodine is a printer's error."

Garrett's The Periodic Law

A book reviewing The Periodic Law by A.E. Garrett, pub. D. Appelton & Co (1909). This work shows the state of knowledge in the first decade of the 20th century.

René Vernon writes:

"On page 43 Garrett notes that, '[Thomas] Carnelley was the first English chemist to work out in detail the manner in which the properties of the elements are periodic functions of their atomic weights. His papers on this subject appeared in the Philosophical Magazine between the years 1879 and 1885.' "

Read more one Carnelley here.

Emerson's Periodic Table of Atomic Weights

Emerson BK, Helix chemica: A study of the periodic relations of the elements and their graphic representation, American Chemical Journal, vol. 45, pp. 160–210 (1911). The formulation below appears on page 173; a scanned pdf version of the paper can be viewed here.

René Vernon writes:

Emerson includes two elements before hydrogen: "E" (either the luminiferous ether or the electron) and "Coronium". There are also two elements between hydrogen and helium: "Nebulium" and "Protofluorine".

This is the first time I have seen a PT showing four extra elements and where they are supposed to fit.

After La, Emerson incorporates 13 lanthanides (Ce to Lu) as transition elements into his 7th period.

Emerson missed dysprosium, between Tb and Ho.

"A, B and C" at the bottom right are supposed to be 'halogen emanations'.

Mark Leach adds that Emerson's very odd Periodic Table of Atomic Weights does not actually show any atomic weights.

Rydberg's Table

René Vernon writes:

My source is the 1914 French translation of Rydberg’s 1913 German article.

• Rydberg 1913, Untersuchungen über das System der Grundstoffe, Lunds Univ. Årsskrift, (Acta Univers, Lundensis), vol. 9, no. 18, pp. 1-41
• — 1914, Recherches sur le système des éléments, Journal de Chimie Physique, vol. 12, pp. 585–639, https://doi.org/10.1051/jcp/1914120585

Friend's Periodic Table (1917)

H. F. V. Little, A Text-Book of Inorganic Chemistry, Vol. IV, Aluminium and its Congeners, including the Rare Earth MetalS (Group III. of the Periodic Table), JN Friend (ed.) Charles Griffin & Company, London (1917), front paper.

Thanks to René Vernon for the tip.

One of Mendelejeff's Tables, Modified

From Smith A 1918, General Chemistry for Colleges, 2nd ed., The Century Co., New York, p. 299

René Vernon writes:

• H is missing, as are the noble gases.
• Consequently, the period numbers are out by one apiece.
• Seven groups are on the left and seven are on the right (the ever present allure of symmetry).
• After La, Ce is placed under Zr, and Nd is placed under columbium/technetium.
• According to Smith the rest of the lanthanide elements do not fit into any series, because their valences and other chemical properties do not permit most of them to be distributed over so many different groups.
• Po is expected to be a metal which is what it turned out to be Smith has anticipated that astatine will be a metal. Nine decades later, Hermann, Hoffmann & Ashcroft (2013) predicted the same thing: Hermann, A.; Hoffmann, R.; Ashcroft, N. W. (2013). Condensed astatine: Monatomic and metallic. Physical Review Letters, 111 (11), 116404-1–116404-5
• While he does not discuss it, Smith appears to have allowed for missing elements between Li and Gl and between Na and Mg.
• The three elements inside square brackets are those predicted by Mendeleev.

Cherkesov: Two Periodic Tables

von Bichowsky FR, The place of manganese in the periodic system, J. Am. Chem. Soc. 1918, 40, 7, 1040–1046 Publication Date: July 1, 1918 https://doi.org/10.1021/ja02240a008

René Vernon writes:

"In this curious article, von Bichowsky, a physical chemist (1889-1951), mounted an argument for regarding Mn as belonging to group 8 (see table 1 below) rather than group 7 (table 2). His article has effectively been assigned to the dustbin of history, having apparently gathered zero citations over the past 103 years.

"Items of note in his 24-column table:

• While Mn, 43 and 75 are assigned to group 8 they remain in alignment with group 7. Se is shown as Sc
• 14 lanthanides, from Ce to Yb, make up group 3a; If La and Lu are included, there are 16 Ln
• Gd is shown as Cd
• Positions of Dy and Ho have been reversed
• Tm and Tm2
• Po shown as "RaF"
• Ra shown as "RaEm"
• Pa shown as Ux2

von Bichowsky made his argument for Mn in group 8, on the following grounds:

• by removing the Ln from the main body of the table all of the gaps denoted by the dashes (in table 2) were removed
• the eighth group links Cr with Cu; Mo with Ag; and W with Au
• the symmetry of the table is greatly increased
• the triads are replaced by tetrads and a group of 16 Ln which accords better with "the preference of the periodic system for powers of two"
• about eight chemistry-based differences between Ti-V-Cr and Mn, including where Mn shows more similarities to Fe-Co-Ni, for example:
  • divalent Ti, V, Cr cations are all powerful reducing agents, Cr being one of the most powerful known; divalent Mn, Fe, Co, Ni are either very mild reducing agents as divalent Mn or Fe, or have almost no reducing power in the case of divalent Co or Ni;
  • metal titanates, vanadates and chromates are stable in alkaline solution and are unstable in the presence of acid whereas permanganates are more stable in acid than alkali; their oxidizing power is also widely different.

I can further add:

• Mn, Fe, and Co, and to some extent Ni, occupy the "hydrogen gap" among the 3d metals, having no or little proclivity for binary hydride formation
• the +2 and +3 oxidation states predominate among the Mn-Fe-Co-Ni tetrad (+3 not so much for Mn)
• in old chemistry, Mn, Fe, Co, and Ni represented the "iron group" whereas Cr, Mo, W, and U belonged to the "chromium group": Struthers J 1893, Chemistry and physics: A manual for students and practitioners, Lea Brothers & Co., Philadelphia, pp. 79, 123
• Tc forms a continuous series of solid solutions with Re, Ru, and Os

Moving forward precisely 100 years, Rayner-Canham (2018) made the following observations:

• Conventional classification systems for the transition metals each have one flaw: "They organise the TM largely according to one strategy and they define the trends according to that organisation. Thus, linkages, relationships, patterns, or similarities outside of that framework are ignored."
• There are two oxide series of the form MnO and Mn3O4 which encompass Mn through Ni. Here the division is not clear cut since there are also the series Mn2O3 for Ti-Cr and Fe; and MnO2 for Ti to Cr.
• Under normal condition of aqueous chemistry, Mn favours the +2 state and its species match well with those of the following 3d member, Fe.

  Rayner-Canham G 2018, "Organizing the transition metals" [a chapter in] in E Scerri & G Restrepo, Mendeleev to Oganesson: A multidisciplinary perspective on the periodic table, Oxford University Press, Oxford, pp. 195–205

I've also attached a modern interpretation of von Bichowsky’s table. It's curious how there are eight metals (Fe aside) capable of, or thought to be capable of, achieving +8. I am not sure that a table of this kind with Lu in group 3 is possible, without upsetting its symmetry."

Snyder's Fundamental Periodic Table of The Elements

Snyder MB 1919, The Fundamental Periodic Table of the Chemical Elements, filed in Congressional Library, Washington.

René Vernon writes:

"Notable for:

• Its attempted integration of the Ln and An into the short form of the periodic table
• Placement of H over He, Li and F
• Elements 108 = Pleon; 126 = Akron; 143 = Ultine"

Click to enlarge

Black & Conant's Periodic Classification Of The Elements

From N.H. Black NH & J.B. Conant's Practical Chemistry: Fundamental Facts and Applications to Modern Life, MacMillan, New York (1920)

Eric Scerri, who provided this formulation writes (personal communication):

"Notice conspicuous absence of H. And, Conant was the person who gave Kuhn his first start in the history of science at Harvard."

René Vernon tells us that Conant and his coauthor write:

"The position of H in the system has been a matter of some discussion, but it is not of much consequence. It seems to be rather an odd element. Perhaps the best place for it is in group IA as it forms a positive ion." (p. 350)

Thanks to Eric Scerri for the tip!
See the website EricScerri.com and Eric's Twitter Feed.

Stewart's Arrangement of The Elements

From A.W. Stewart, Recent Advances in Physical and Inorganic Chemistry, 3rd ed., Longmans, Green and Co., London (1920)

René Vernon writes:

"Stewart discusses the 'forced symmetry' of Mendeleev's table, and the distinction between 'facetious symmetry' (as he calls it) and the actual correlation of facts (as he saw them at that time)."

Extracts:

237. Mendeleev... objected strongly to the employment of graphic methods of expressing the Periodic Law, on the ground that such methods did not indicate the existence of a limited and definite number of elements in each period.

239. The Periodic Table, as laid down by Mendeleeff in his writings, exhibits a symmetry which was one of its greatest assets. For some psychological reason, symmetry has an attraction for the human mind; and we are always apt to prefer a regular arrangement to one in which irregularities pre- dominate. Psychological peculiarities are, however, undesirable guides in the search for truth; and a careful examination of the Table in the light of our present knowledge will suffice to show that it can boast of no such symmetry as we are led to expect from the text-books of our student days.

For example, owing to the omission of some of the rare earth elements and by the insertion of blanks, the Table in its original form attained a very high degree of regularity; but since there are, as we know from the X-ray spectra results, only sixteen elements to fill the eighteen vacant spaces in the Table, it is evident that the symmetry of Mendeleeff s system is purely factitious.

Further, in order to produce the appearance of symmetry, Mendeleeff was forced to place copper, silver, and gold in the first group, although there is no known oxide Au₂O and the stable chloride of gold is AuCl₃.

These examples are well-known, and are mentioned here only for the purpose of enforcing the statement that the symmetry of Mendeleef's system cannot be sustained at the present day. Fascinating though its cut-and-dried regularity may be, we cannot afford to let symmetry dominate our minds when in actual fact there is no symmetry to be found.

240. The most superficial examination shows that, instead of being a symmetrical whole, the Table is really pieced together from a series of discrete sections.

250. The first attempt to arrange all the elements in a periodic grouping took the form of a three-dimensional model the Telluric Helix of de Chancourtois and it is not surprising that from time to time attempts have been made to utilize the third dimension as an aid to classification. It cannot be said that much light has been thrown on the matter by these essays; but some account of them must be given here for the sake of completeness.

251. The main drawback to the spiral representation appears to be that in it no new facts are brought to light, and there is no fresh collocation of the allied elements which might give it an advantage over the ordinary forms of classification. Also, in most cases it is more difficult to grasp as a whole.

253 ...if we have to choose between factitious symmetry and actual correlation of facts, we must decide in favour of the latter, discomforting though the choice may be.

255. The following new grouping seems worth considering. Although it has many good points, it is not to be regarded as a final solution, but is put forward mainly in the hope that an examination of it may suggest some more perfect system.

Formánek's Periodic Table

Formánek J. 1921, Short Outline of Inorganic Chemistry (in Czech), 2nd ed., Ministerstvo zemedelstvi CSR, Praha. p. 281

René Vernon writes:

Here is an eight column table with some interesting features.

Main groups 0, Ia, IIa, Vb, VIb, and VIIb, correspond to what we have today:

• 0 Noble gases
• Ia Alkali metals
• IIa Alkaline earths
• Vb Pnictogens
• VIb Chalcogens
• VIIb Halogens

Main group IIIa is B-Al-Sc-Y... Ac whereas these days B-Al have been moved over Ga on electronic grounds. This happened despite the fact that the average trend line for chemical and physical properties v Z going down B-Al-Sc-Y... Ac is more regular.

In main group IV, notice how C and SI are positioned in the middle of the cell, unlike their neighbours to either side. The group thus bifurcates after Si into a Ti branch and a Ge branch. This is quite reasonable since there is not much difference in the average trendlines going down either option. In any case, C-Si came to be moved over Ge again on electronic grounds.

He survived the electronic revolution, staying over Ne.

Margary's Modified Table

Ivan D. Margary B.A. (1921) XXXVI. A modification more in accord with atomic structure, The London, Edinburgh, and Dublin Philosophical Magazine and Journal of Science, 42:248, 287-288.

An old school table showing group 3 as B-Al-Sc-Yt-Rare earths.

Thanks to René for the tip!

Fajans' Periodic Table

Fajans K., Radioactivity and the latest developments in the study of the chemical elements, trans. TS Wheeler, WG King, 4th German edition, Methuen & Co., London, pp. 116-117, 1923.

René Vernon writes: "An addition to the long list of tables with B-Al over Sc."

Deming's Periodic Table With Commentry by Vernon

René Vernon writes:

Deming's 1923 periodic table is credited with popularizing the 18-column form.

I now see Deming used different thickness sloping lines to represent the different degrees of similarity between the main groups and their corresponding transition metal groups.

• The line between Li-Na and group 11 is dashed, denoting the weakest relationship.
• Be-Mg are in group 2 The line between Be-Mg and group 12 is not dashed, denoting a stronger relationship.
• B-Al are in group 3
• The line between B-Al and Ga-In-Tl is thicker yet.

When I plot up to 20 chemical properties v Z going down these options I get the following values for the average smoothness of the trendlines:

• 73.5% for Li-Na-Cu(+2)-Ag(+1)-Au(+3) versus 84% for Li-Na-K-Rb-Cs
• 70% Be-Mg over Zn versus 85% for Be-Mg-Ca-Sr-Ba
• 81% for B-Al-Ga-In-Tl versus 88% B-Al-Sc-Y-La

I would have thought the smoothness for the line between Li-Na and Cu would be < 70%, consistent with Deming’s dashed line. But the thickness of the line would depend on what Deming took into account when he drew it. The common wisdom about groups 1 and 11 is that their similarities are: "confined almost entirely to the stoichiometries (as distinct from the chemical properties) of the compounds in the +1 oxidation state." (Greenwood & Earnshaw 2002, p. 1177). Kneen et al. (1972, p. 521) say that, "the differences between the properties of the group IA and IB elements are those between a strongly and weakly electropositive metal." On this basis I follow Deming’s dashed line. I’ve appended some notes about Group 1 and Group 11.

• Main group 4 is C-Si-Ge-Sn-Pb
• The line between Si and Ti-Zr-Hf is thick
• The line between N-P and V is less thick
• The line between O-S and Cr is less thick again
• The line between F-Cl and Mn is dashed

I have [calculated] a smoothness for C-Si-Ti-Zr-Hf of 86% versus 70% for C-Si-Ge-Sn-Pb. Since Ti shows some transition metal chemistry but not C-Si, it is perhaps plausible to keep C-Si-Ge-Sn-Pb together (as Deming did ).

Deming was a smart author. Nigh on a century later and the metrics check out.

More about group 1 and group 11

There may be a little more to the relationship between Li-Na & Cu-Ag-Au, than is ordinarily appreciated. For example:

• The resulting composite "group" has two electropositive metals and three more electronegative metals so its overall nature is more nuanced then purely group 1 or purely group 11
• The ionic radii of Li+ and Cu+ are 0.76 and 0.77 Å, and there is at least some discussion in the literature about substitution phenomena (Vasilev et al. 2019, p. 2-15; Udaya et al. 2020, p. 98; Kubenova 2021 et al.)
• Group 1 and 11 metal atoms form clusters relatively easily including Au_4²⁺, Ag_6⁴⁺, Rb_7⁵⁺, Na_4³⁺ (Mile et al. 1991, p. 134; Wulfsberg 2000, p. 631).
• In an organometallic context, Schade & Scheyler (1988, p. 196) wrote that, "There is much evidence that differences between group 1 and group 11 metals are not of principal but rather gradual manner."
• Although most nonmagnetic metals exhibit superconductivity it is significant that the Group 1 and 11 metals do not become superconducting at very low temperatures (Rao & Gopalakrishnan 1997, p. 398).
• Gold forms intermetallic compounds with all alkali metals (Schwerdtfeger et al. 1989. p. 1769)

References

• Greenwood NN & Earnshaw A 2002, Chemistry of the Elements, 2nd ed., Butterworth Heinemann, Oxford
• Kubenova et al. 2021, "Some thermoelectric phenomena in copper chalcogenides replaced by lithium and sodium alkaline metals", Nanomaterials 2021, vol. 11, no. 9. article 2238, https://doi.org/10.3390/nano11092238
• Mile et al. 1991, "Matrix-isolation studies of the structures and reactions of small metal particles", Farady Discussions, vol. 92, pp. 129–145 (134), https://doi.org/10.1039/FD9919200129
• Rao CNR & Gopalakrishnan J 1997, New Directions on Solid State Chemistry, 2nd ed., Cambridge University Press, Cambridge
• Schade C & Schleyer PVR 1988, "Sodium, potassium, rubidium, and cesium: X-Ray structural analysis of their organic compounds", Advances in Organometallic Chemistry, vol. 27, Stone FGA & West R (eds), Academic Press, San Diego, pp. 169–278
• Schwerdtfeger et al. 1989, "Relativistic effects in gold chemistry. I. Diatomic gold compounds.", The Journal of Chemical Physics, vol. 91, no. 3, pp. 1762–1774. https://doi.org/10.1063/1.457082
• Udaya et al. 2020, Metal sulphides for lithium-ion batteries, in Inamuddin, Ahmer & Asiri (eds), Lithium-ion batteries: Materials and applications, Materials Research Forum, Millersville PA, pp. 91–122
• Vasiliev AN et al. 2019, Low-dimensional Magnetism, CRC Press, Boca Raton
• Wulfsberg 2000, Inorganic chemistry, University Science Books, Sausalito, CA

Courtines' Model of the Periodic Table or Periodic Classification

Published in J. Chem. Ed., 2, 2, 107-109 in 1925 by M. Courtines of the Laboratory of Experimental Physics, College of France, Paris.

Q&Q write:

"The unfolded tower arrangement appears much like a modernised Chauvierre chart cut on a line between Ni and Cu, Cu, with the right part fitted to the left in order of increasing atomic numbers. The rare-earth elements, however, are placed on a novel accordion-like folded strip with ends made secure just below Xt and between Ba and Hf. The author describes in detail the method of folding the chart into a tower-like cylindrical model. H is folded back to show its lack of relationship other groups of elements. In the space for each symbol, electron arrangements and isotopes are also enumerated."

And, in what appears to be a 'top down' view of the above 3D formulation, Courtine M 1926, Oùen est la physique, Gauthier-Villars et Cie, Paris:

Thanks to Eric Scerri for the tip & René Vernon's additions! See the website EricScerri.com and Eric's Twitter Feed

Friend's Periodic Table (1926)

Vallance RH & Eldridge AA, A Text-Book of Inorganic Chemistry, Vol. VII, Part III, Chromium and its Congeners, JN Friend (ed.) Charles Griffin & Company, London (1926), front paper.

René Vernon (who found this formulation) writes:

"I can't recall seeing a table in which the lanthanoids were allocated in quite such a manner: across seven groups. And, 16 such lanthanoids shown. Even curiouser, Argon = A; xenon = X; are shown in group 0. Wonderful nomenclature from nearly a century ago."

LeRoy's Periodic Table

R.H. LeRoy, Teaching the Periodic Classification of Elements, School Science and Mathematics 1927, 27: 793-799. This formulation thulium in group IC and has the actinides in the C groups, analogous to the lanthanides, two decades before Seaborg.

René adds:

"This 1927 formulation has several remarkable features.

"The lighter and heavier lanthanides and actinides are shown in numbered C groups i.e. C4, C5, C6, C7 and C1, C2, and C3. The 14 remaining elements between C7 and C1 are labelled as transition elements, analogous to the old chemistry notion of the ferromagnetic and platinum metals in IUPAC groups 9 to 11 being labelled as transition elements. There is no known Tm(I) although this would not be inconceivable. Nd is in group C6, which doesn't quite work since there is no Nd(VI) although such an oxidation state is not inconceivable given the existence of Pr(V). in group C7, Pm(VII) is not known. For the actinides, Md(I) has been reported but not confirmed.

"B-Al-Sc-Y-La-Ac are shown as main group metals; that would be consistent with their chemistry. While Sc-Y-La-Ac are routinely classified as transition metals their chemistry is largely that which would be expected of main group metals following the alkaline earths in IUPAC group 2.

"The author refers to the noble gases as 'transitional'. The noble gases bridge the most reactive groups of elements in the periodic table – the alkali metals in group I and the halogens in group VII. That's a concept that's rarely referred to these days even though it's still quite valid.

"Ga-In-Tl are shown as B3 metals, falling just after Zn-Cd-Hg in group B2, and Cu-Ag-Au in group B1. That doesn't work for Ga etc, which are nowadays regarded as main group metals.

"H is shown floating above the A elements, and in the transitional zone, with links to F and to Li."

Thanks to John Marks for the tip, and to René for the comments/analysis!

Gardner's Table of Electronic Configurations of the Elements

A table of electronic configurations of the elements. Nature 125, 146 (1930). https://doi.org/10.1038/125146a0

Abstract:

"MR. ROY GARDNER gave an interesting paper on A Method of Setting out the Classification of the Elements at a recent meeting of the New Zealand Institute. The paper included the accompanying Table, which shows the distribution of electrons into groups corresponding to the principal quantum numbers for all the elements and at the same time preserves the most essential features of the two-dimensional arrangement of Mendeleef. Elements having the same complete groups (that is, all stable groups of 8 or 18) are placed in the same horizontal row, and the vertical columns include elements with the same number of electrons in the incomplete outer groups. The electronic configurations are those given by Sidgwick ("Electronic Theory of Valency", 1927). An asterisk marks elements for which the 'normal' atom is thought to have only one electron in the outermost group, but as practically all these give divalent ions, the point is of minor interest chemically. Distribution of electrons into k-subgroups is unnecessary; these have at present little significance for chemical purposes, and in any case the subgroups are considered to be filled in order to the maxima 2, 6, and 10."

René Vernon writes:

In this table Gardner emphasises the existence of four types of elements:

1. those with all "groups" complete
2. those with one incomplete group
3. those with two incomplete groups (transition elements)
4. those with three incomplete groups (rare earth elements)

The upper limits of existence of covalencies of 8, 6, and 4 are marked by heavy horizontal lines.

Note:

• there are nine groups of d-block elements [as we would now call them], and but 13 f-block elements
• La and Lu are treated as d-block elements
• while Yb is counted as an f-block element it was later realised (1937) that the 4f shell is full at Yb, hence it is not clear where Gardner would have placed it (Yb)—seemingly in the 0 column

LeRoy's Periodic Table

R.H. LeRoy, Teaching the Periodic Classification of Elements, School Science and Mathematics 1927, 27: 793-799. This formulation thulium in group IC and has the actinides in the C groups, analogous to the lanthanides, two decades before Seaborg.

René adds:

"This 1927 formulation has several remarkable features.

"The lighter and heavier lanthanides and actinides are shown in numbered C groups i.e. C4, C5, C6, C7 and C1, C2, and C3. The 14 remaining elements between C7 and C1 are labelled as transition elements, analogous to the old chemistry notion of the ferromagnetic and platinum metals in IUPAC groups 9 to 11 being labelled as transition elements. There is no known Tm(I) although this would not be inconceivable. Nd is in group C6, which doesn't quite work since there is no Nd(VI) although such an oxidation state is not inconceivable given the existence of Pr(V). in group C7, Pm(VII) is not known. For the actinides, Md(I) has been reported but not confirmed.

"B-Al-Sc-Y-La-Ac are shown as main group metals; that would be consistent with their chemistry. While Sc-Y-La-Ac are routinely classified as transition metals their chemistry is largely that which would be expected of main group metals following the alkaline earths in IUPAC group 2.

"The author refers to the noble gases as 'transitional'. The noble gases bridge the most reactive groups of elements in the periodic table – the alkali metals in group I and the halogens in group VII. That's a concept that's rarely referred to these days even though it's still quite valid.

Ga-In-Tl are shown as B3 metals, falling just after Zn-Cd-Hg in group B2, and Cu-Ag-Au in group B1. That doesn't work for Ga etc, which are nowadays regarded as main group metals.

"H is shown floating above the A elements, and in the transitional zone, with links to F and to Li."

Thanks to John Marks for the tip, and to René for the comments/analysis!

Bacher & Goudsmith's Periodic System and Index

R.F. Bacher RF and S.A. Goudsmith, Atomic Energy States, McGraw-Hill, New York, p. xiii. 1932:

Thanks to René for the tip!

Bejerrum's Periodic Table

Bjerrum N, Inorganic chemistry, trans. (1936) from the 3rd Danish edition (1932) by N Bjerrum and RP Bell, William Heinemann, London

https://en.wikipedia.org/wiki/Niels_Bjerrum

René Vernon observes:

• There are split blocks everywhere in Bjerrum's periodic system: s once; f once; d twice; p twice.
• As per old chemistry: B and Al are over Sc
• The group numbering is interesting: eight groups and eight sub-groups
• Bjerrum says the metals fall naturally into two groups: the light metals with a density below 4 gm/cm^3; the heavy metals with a density above 7 gm/cm^3, many of which form coloured salts
• Bjerrum refers to the transition metals as being those in subgroups 8a, 8b and 8c

Rysselberghe's Periodic Table

Pierre Van Rysselberghe J. Chem. Educ. vol. 12, no. 10, pp. 474—475 1935.

The author writes:

"The usual relationships between analogous elements are preserved and are in fact emphasized by this new arrangement. The only missing regularity is the natural succession of atomic, numbers, but all periodic classifications have to sacrifice it on account of the rare earths. Moreover, it can easily be restored by reading the horizontal lines n the order indicated by the numbers written on the left of the heavy frame line. Each horizontal line is limited by the frame of the table. For instance, K and Ca on the one hand, Cu and Zn on the other hand, form two distinct horizontal lines, as shown by the different numbers given to these groups. They are at the same level because the valence electrons have the same quantum numbers."

Thanks to René for the tip!

Van Wert Periodic table (after Guertler-Leitgebel)

Van Wert LR, An Introduction to Physical Metallurgy, McGraw-Hill, New York, 1936, pp 17. Van Wert says the periodic table is after "Guertler-Leitgebel", which is presumably Guertler WM & Leitgebel M 1929, Vom Erz zum metallischen Werkstoff: Leitlinien und Rüstzeug der metallurgischen und metallkundlichen Wissensgebiete, Akademische Verlagsgesellschaft, m.b.H., Leipzig

From René Vernon who writes:

In this almost symmetrical presentation, Van Wert divides the periodic table metals into:

Strongly Electropositive:       Groups 1 to 3, Ln
High-melting Heavy Metals:   Transition metals
Low-melting Heavy Metals:    Post-transition metals

If the 15 Rare Earths had been shown as 14, and moved one cell to the left we would have a perfectly symmetrical table.

Elsewhere (p. 38) Van Wert refers to the noble metals as follows:

"With respect to corrosion, the noble metals — gold, the platinum metals, and to a less degree, silver — are in a class by themselves. They are comparatively chemically inert to all common corrodents; only silver is appreciably attacked by sulphur gas."

Van Wert's table also refers to non-metals and to inert gases. On page 7 mention is made of the metalloids:

"There are a few elements, also, that partake of the nature of both metals and nonmetals, under many—indeed, under most—conditions they seem metallic enough, but on occasion their behavior is decidedly nonmetallic. These metalloids, as they are sometimes called, add a further difficulty in the attempt to frame a satisfactory definition of the metallic state."

By 1936, it was known that metalloids had a predominately nonmetallic chemistry (Newth 1894, pp. 7??8; Friend 1914, p. 9). So, on the nonmetal side of house are metalloids; "nonmetals"; and noble gases. Separating out the halogens from the nonmetals yields: metalloids; "nonmetals"; halogens; noble gases.

The net result is four types of metals and four of nonmetals = more symmetry.

Foster's Periodic Arrangement

L.S. Foster, "Why not modernise the textbooks also? I. The periodic table", Journal of Chemical Education, vol. 16, no. 9, pp. 409–412, https://pubs.acs.org/doi/10.1021/ed016p409

Foster writes:

"The [above] modern periodic table is simply an orderly array of the elements with all unnecessary ornamentation omitted, has been found highly satisfactory for instructional purposes.

"The transitional elements, with two unfilled electron shells, are separated from the non-metallic elements.

"The rare-earth elements, defined as those with three incomplete electron shells, are shown to be those of atomic numbers 58 to 70, while La and Lu, which have only two incomplete electron shells are classified as transitional elements.

"Copper, silver, and gold act as transitional elements except when the state of oxidation is one."

René Vernon writes:

Foster couldn't show the coinage metals – with their full d¹⁰ complements – as transitional elements, but by adding a broken line around them he was showing they had the capacity to act as if they were.

I tried to work out how he distinguished La & Lu from Ce to Yb. Foster seems to be saying that La 5d¹ 6s², has incomplete 5th and 6th (ie. 6p) shells.

Same for Lu 4f¹⁴ 5d¹ 6s² having incomplete 5th and 6th shells. Whereas, for example, Ce 4f¹ 5d¹ 6s² has incomplete 4th, 5th and 6th shells. Presumably this was in the years before the fact that the 4f shell became full at Yb was widely appreciated. So, strictly speaking, group 3a should have read:

On the other hand, Yb³⁺ has an f¹³ configuration, so it does meet his three unfilled shells criterion. Had he known, he probably would've put a broken line around Yb to indicate its full f¹⁴ complement but that it normally acted as a rare earth, with an incomplete 4f shell; whereas neither La nor Lu have this capacity.

Good to see Foster put so much thought into organising his table, and his experience with using it for instructional purposes.

Van Spronsen does not mention Forster's table. Mazurs has a reference to Foster's table but lumps it in with the other medium-long tables, not appreciating its subtlety.

Mark Leach writes:

This formulation is very much like the XBL 769-10601, Periodic Table Before World War II used by Seaborg and the Manhattan project and is a precursor to the modern periodic table.

Periodic Chart in Spiral Form

Periodic Chart in Spiral Form from K. Gordon Irwin, Periodicity Patterns of The Elements J.Chem.Ed. 1939 16 (7), 335 DOI: 10.1021/ed016p335

Thanks to René Vernon for the reference:

Hsueh & Chiang's Periodic Properties of the Elements

Hsueh & Chiang, Periodic Properties of the Elements, J. Chinese Chem. Soc., 5, 5, 253-275. See the PDF.

René Vernon writes:

"A mathematical expression of the periodic law was put forward in 1937 in an article by Chin-Fang Hsueh and Ming-Chien Chiang: J Chinese Chem Soc, 5, 263 (In English.) They derived a property equation from which the numerical magnitude of a property P is related to the atomic number Z of the element in question in terms of valence V, a function of the periodic factor y, the principal quantum number n, and two parameters a and p, which are constants for a given family of elements but different for different families."

Emerson's Spiral Formulation

Emerson EI, 1944, A new spiral form of the periodic table, JChemEd., vol. 21, no. 3, pp. 111–115

René Vernon writes:

Emerson says that the elements in the A groups are called the representative elements because, as Eble states, they "include metals, nonmetals, inert elements, liquids, and gases." Eble RL, 1938, Atomic structure and the periodic table, JChemEd., vol. 15, p. 575

Note the inclusion in Emerson’s table of the neutron as element 0. Astonishingly, Emerson writes: "Element 0, possibly neutron [sic], is considered as a noble gas. Because of its probable chemical inertness and extreme density it might not be detected in a sizeable amount until some future scientist succeeds in sampling the center of the Earth." (p. 111)

(Mark Leach adds: The date is 1944 when the Manhattan Project was in full swing and nothing was being published about nuclear physics and/or neutron interactions. This idea may have come from some type of Popular Science story?)

Other features:

• The A and B groups are diametrically opposed in their positioning. "The electron structure of H either as H⁺ or H^– finds a counterpart in the structure of element 0 or 2." (p. 113)
• The cell spaces for Be and Mg have been stretched on account of uncertainty as to whether they belong to group 2 or group 12. "The break between the periphery of the loops of the spiral along the spaces allotted to Mg and the transition metals of the fourth period serves to indicate that Be and Mg are not to be considered as a kind of prototype of these groups." (p. 111)
• "The C group is shown as a separate segment. If one were not concerned by plane representation the rare earths could be represented as a loop or bulge above the surface of the plane. One might imagine that this group of metals is a sort of hernia of nature that has been excised so as to maintain a flat surface." (p. 112–113)

Emerson's Long Chart Modified to Show Atomic Structure

Edgar I. Emerson 1944, A chart based on atomic numbers showing the electronic structure of the elements, J. Chem. Educ. 1944, 21, 5, 254.

A WWII chart showing neutronium over He, and a split d-block.

Thanks to René for the tip!

Talpain's Gnomonic Classification of the Elements

Talpain PL 1945, Gnomonic classification of elements, J.Phys. Radium 6, 176-181 (in French), https://doi.org/10.1051/jphysrad:0194500606017600

Talpain writes:

"To overcome the drawbacks presented by the various tables in rows and columns into which the classification of chemical elements is usually inserted, the author proposes a diagram in space, having the form of a double pyramid constructed according to a simple arithmetic law, inspired by Greek surveyors. Under these conditions, all the bodies belonging to the same chemical family are placed on the same column, and all those which have similar physical properties (magnetic, electrical, radioactive, crystallographic, rare earths, etc.) are grouped together. This same diagram also makes it possible to represent the electronic structure of the atoms, the quantified states of the electrons, the energy levels and the spectral lines of hydrogen. Perhaps spectroscopists will be able to use it to also represent the lines of other bodies."

Thanks to René for the tip!

Achimof's System

Van Spronsen, on p. 157, says:

"Achimov's system took the form of a cross-section of a pyramid. He based his system on the principle that the lengths of the periods and the analogies in properties between the elements of these periods must be clearly demonstrated."

Achimov EI 1946 Zhur. Obshchei Khim., vol. 16, p. 961

Thanks to René for the tip!

Yost & Russell's Periodic System

From D.M. Yost & H. Russell, Systematic Inorganic Chemistry of the Fifth-and-Sixth-group Nonmetallic Elements, Prentice-Hall, 1946, New York, p. 406.

René Vernon writes:

"Features of this peculiar periodic system:

• There are 11 main groups
• Group 3 features B-Al, followed by Sc-Y-La-Ac
• Group 4 bifurcates after C-Si into a Ti branch and a Ge branch; seemingly the Ti branch bifurcates after Zr into a Ce branch and a Hf branch
• Group 8 is Fe-Ru-Os
• Group 9 is Co-Rh-Ir
• Group 10 is Ni-Pd-Pt
• There are only 13 rare earths, running from Pr to Lu.

Harrington's Crystal Chemistry of the Periodic System

R.H. Harrington, The Modern Metallurgy of Alloys, John Wiley & Sons, New York, p. 143 (1946)

René Vernon writes:

"The numbers below each element symbol refer to the crystal: 1 = FCC, 9 = graphite structure, 11 = orthorhombic, etc. Extra numbers are for structures at higher temperatures.

"The wriggly lines between groups 3 and 4, and 11 and 12 refer to a gradation between the classes involved. Wikipedia calls these linking or bridging groups

"Harrington's class names are novel. [Who would have thought of the elements of groups 1 to 3 as being called the "salts of electrons"?] Then again, "in view of the extensive role that electrons play as anions" Dye (2015) asked: "where should electrons be placed in the periodic table?" (Note: In 1946 Achimof tried answering this, with an electron as element -1 above H and a neutron as element 0 above He.)

"Aluminium appears in group 3 and group 13 since, according to Harrington, it has the crystalline structure of a true metal. This is not quite true since its crystalline structure shows some evidence of directional bonding.

"For the transition metals as "wandering bonds", Harrington writes that the metallic bond is spatially undirected and that it may operate between any given atom and an indefinite number of neighbours" (p. 145). Since A-metals are better called, in his mind, "salts of electrons" [and B-metals show signs of significant directional bonding] the transition metals are therefore called by him as wandering bonds. This becomes confusing, however, given d electrons in partially filed d-orbitals of transition metals form covalent bonds with one another.

"Counting boron as a pseudo metals looks strange.

"Germanium is counted as a metal: "...the electrical conductivit[y]... [is] sufficiently high to show that the outer electrons are very loosely held and the linkage must be partly metallic in character." (p. 148). In fact the electrical conductivity of high purity germanium, which is a semiconductor, is around 10^–2S.cm^–1. Compare this with antimony, at 3.1 x 10⁴S.cm^–1

"Tin has brackets around it to show its "renegade" status, "with its white form behaving largely as would a True Metal, whereas its grey form is more non-metallic than metallic." White tin actually has an irregularly coordinated structure associated with incompletely ionised atoms.

"Thallium and lead have brackets around them since their crystalline structures are supposedly like those of true metals. This is not quite right. While both metals have close-packed structures they each have abnormally large inter-atomic distances that have been attributed to partial ionisation of their atoms.

"The B-subgroup metals are divided into pseudo metals and hybrid metals. The pseudo metals (groups 11 and 12) behave more like true metals than non-metals. The hybrid metals As, Sb, Bi, Te, Po, At – which other authors would call metalloids – partake about equally the properties of both. According to Harrington, the pseudo metals can be considered related to the hybrid metals through the carbon column.

"The location of the dividing line between metals and nonmetals, running as it does through carbon to radon is peculiar. The line is usually shown running through boron to astatine."


Top of Page

---

Year:  1947

PT id = 85, Type = formulation spiral

Stedman's Design

In his article Stedman says:

• The planar arrangement differs from the plan of his solid model, 'only as necessary to clarify the presentation'
• One the major features is that only two groups, at Si and Y, are considered to be 'truly' branched and that the latter 'is not usually considered in this manner'
• The smaller symbols, such as V under P, aren't necessary but are 'merely offered for consideration'
• Si shows a greater resemblance to Ge than it does to the closer Ti, while Y similarly shows greater resemblance to Lu than to La
• Stedman first drew his first version of this table sixteen years ago (= 1931)



Thanks to René for the tip!

Top of Page

---

Year:  1947

PT id = 1166, Type = formulation

Ageev's Crystalline Structures of The Elements

Ageev NV 1947, The nature of the chemical bond in metal alloys (Izdvo Akad. Nauk SSSR, Moscow/Leningrad, p. 10

René Vernon writes:

"In this curious 18-column table, showing the crystalline structures of the elements, Ageev locates the predominately non-metallic groups on the left and the remaining groups on the right.

"It's odd that he located boron and aluminium on the far left over gallium, rather than over scandium. I suppose he did this so that gallium, indium, and thallium would not be mistaken for d-block metals.

"Reading from left to right then, Ageev's table could be said to be made up of five blocs:"

[1] the nonmetallic bloc
[2] the alkaline bloc
[3] the inner transition bloc
[4] the transition metal block
[5] a post-transition metallic bloc


Top of Page

---

Year:  1947

PT id = 1243, Type = formulation

Science Service: Two Periodic Tables

A two-sided Science Service periodic table from 1947. The one is listed as "After Bohr", the other as "After Mendeleeff".

René Vernon writes:

"Here’s a slightly odd table (with two sides):

1. The neutron is included in group 0.
2. Argon is still A; niobium Cb
3. There's a blank space for Pm (discovered 1945).
4. The main groups are recognisable, with the exception of group 3 as B-Al-Sc-Y-La. The other side of the table lists B-Al as being analogous to Sc-Y-La, rather than Ga-In-Tl.
   The former option works better than the latter in terms of the quantitative smoothness of chemico-physical trend lines going down the group."





Top of Page

---

Year:  1949

PT id = 1052, Type = formulation

Catalán's Periodic System/Sistema Periodico Ampliado

Two versions of Catalán's Periodic System/Sistema Periodico Ampliado. The first from C.E. Moore 1949, Atomic Energy Levels, National Bureau of Standards, Circular no. 467, Washington DC, vol. 1, table 25 (1949) and the second as referenced here: http://www.miguelcatalan.net/pdfs/bibliografia/biblio09.pdf.

René Vernon, who provided the graphics, writes:

"I feel the footnote along the base of the first table could merit better attention being drawn to it. It says:

This arrangement is by Catalán. The electrons indicated in column two that are connected by braces have approximately the same binding energy. Consequently, for some elements one type of electron is preferred over another in the normal configuration, as for example, Cr, Cb, Pd, La, Ac, Th.

"The connecting braces hone in on the source of much of the controversy concerning notions of an ideal, optimal, better, this or that, or fundamental periodic table. I can't recall seeing a table with such a feature. For the second table, turning it on its side (attached) reminds of the ADOMAH [formulation].

Click on the images to enlarge:





Thanks to René for the tip!

Top of Page

---

Year:  1949

PT id = 1018, Type = formulation 3D

Scherer's Student Model of Spiral Periodic Chart

George A. Scherer, New Aids for Teaching the Periodic Law, School Science and Mathematics, vol. 49, no. 2 (1949).

René Vernon writes:

"This is a Left-Step periodic table with a split d-block, that can be rearranged into a cylinder. Students were expected to keep a copy of the two halves of the table in their note books, for reassembly as required. It was a clever way of introducing the 32-column form, and the transition from 2D to 3D (that faded into obscurity)":





Thanks to René for the tip!

Top of Page

---

Year:  1950

PT id = 1080, Type = formulation

Sidgwick's Periodic Classification (Mendeleeff)

From N.V. Sidgwick, Chemical Elements and Their Compounds, vol. 1, Oxford University, London, p. xxviii (1950).

René Vernon writes:

"In this curious table the Lanthanides are located in group IIIA while the Actinides have been fragmented.

Instead:

• Ac, Th, and Pa are located in groups IIIA, IVA and VA under Lu, Hf, and Ta, respectively
• The uranides, U, Np, Pu, Am, and Cm, are located in group VIA, under W."

Sidgwick writes:

"This subgroup (VIA) consists of Cr, Mo, W, and U, to which the 'uranide' elements, Np, Pu, Am, and Cm (which might be assigned to any Group from III to VI) must now be added." (p. 998)

"...the trans-uranium elements 93–6... for the first time give clear evidence of the opening of the 'second rare earth series', the 'uranides', through the expansion of the fifth quantum group from 18 towards 32." (p. 1069)

"The question whether the fifth quantum group of electrons which is completed up to 18 in gold begins to expand towards 32, as the fourth does in cerium, has now been settled by the chemical properties of these newly discovered elements. In the Ln the beginning of the expansion is marked by the main valency becoming and remaining 3. With these later elements of the seventh period there is scarcely any sign of valencies other than those of the group until we come to uranium... Up to and including uranium, the group valency is always the stablest, but beyond this no further rise of valency occurs, such as we find in rhenium and osmium. Hence the point of departure of the new series of structures (corresponding to lanthanum in the first series) is obviously uranium, and the series should be called the uranides. (p. 1092):


Top of Page

---

Year:  1950

PT id = 1119, Type = formulation 3D

McCutchon's Simplified Periodic Classification of the Elements

McCutchon KB, A simplified periodic classification of the elements, Journal of Chemical Education, vol. 27, no. 1, pp. 17–19 (1950)

This 3-dimensional table has two double-sided flaps attached. The top flap is the f bock. Under that is the d block.

The superscripts denote the number of d electrons an element has. Thus, La¹ is shown as being an f¹ element. But it has a 1 superscript, meaning that the f electron count is reduced by 1 and the d electron count is 1.

René Vernon writes:

"On group 3, McCutchon cryptically says: The proposed arrangement brings out certain known facts about the tertiary elements which are rarely shown by other arrangements. For example, it suggests, correctly, that the resemblance between yttrium and lutecium is greater than that between yttrium and lanthanum. It classifies lanthanum but not lutecium as a rare earth, in accordance with their chemical properties (which also contradict spectrographic evidence at this point). It also demonstrates the tetravalence of both cerium and thorium, and that thorium and protactinium show a resemblance in chemical properties to zirconium and niobium, as well as to hafnium and tantalum."

I say "cryptically" because McCutchon presents no further evidence in support of his assertion that the resemblance between Y and Lu is greater than between Y and La. He may have had in mind the fact that Lu is more often found in ores of Y than is the case for La... and I don't understand his reference to spectrographic evidence.






Top of Page

---

Year:  1951

PT id = 1324, Type = formulation

Kapustinsky's Structure of The System of Elements

René Vernon writes:

Kapustinsky AF 1951, Structure of the periodic table of chemical elements (in Russian), Proceedings of the USSR Academy of Sciences, vol. 81, no. 1, pp. 47–50

Below the title Kapustinsky gives two equations that he says determine the structure of the system:

• The equation of periods Š = 4 x n²;
• The equation of cycles/dyads S = 2(n²₁ + n²₂).

The legend at the bottom left is:

• Period
• Cycle
• Number of elements

Kapustinsky refers to the periodic system of elements in terms of its emergence (proto-elements), formation (typical elements), and disintegration (synthetic elements). Kapustinsky refers to e, n, H, He as "proto-elements".

The electron and the neutron are not chemical elements but are elements in the sense of each being a rudiment, which means a beginning; an initial or imperfect form or stage. As Kapustinsky says, the properties of ordinary elements are not yet associated with them.

H and He can be considered "proto-elements" in the sense that they were the first building blocks from which heavier elements were later formed through nucleosynthesis in stars. Kapustinsky says that the system is thus:

• a harmonious whole, with a beginning and end
• regular and symmetrical
• without exception, it embraces all of its constituent members with simple mathematical expressions

Top of Page

---

Year:  1951

PT id = 1245, Type = formulation

Friend's Updated Periodic Table

René Vernon writes:

"This 1951 table succeeds Friend’s table of 1926. Notice how Pu, Am, and Cm have been assigned to group VIII. The splitting of the Ln across two periods is bizarre."


Top of Page

---

Year:  1951

PT id = 1272, Type = formulation

Spedding's Rare Earths Periodic Table

Ref: Spedding FH 1951 The Rare Earths, Scientific American, vol. 185, no. 5, pp. 26–31



Thanks to René for the tip!

Top of Page

---

Year:  1952

PT id = 1054, Type = formulation

Coryell's Periodic Table in Long Form

Charles D. Coryell The periodic table: The 6d-5f mixed transition group, J. Chem. Educ., vol. 29, no. 2, pp. 62–64 1952.

Coryell (1912–1971), was an American chemist involved in the discovery of promethium.

René Vernon writes:

"In Coryell's table, just two elements are shown as having two solid 'tie lines':

Yttrium: to La-Ac and to Lu-Ac

Silicon: to Ti-Zr-Hf and to Ge-Sn-Pb.

"These days Ti-Zr-Hf-Rf is deemed to make-up group 4 (rightly so given group 4 is the first to exhibit characteristic transition metal properties) whereas C-Si-Ge-Sn-Pb-Fl is deemed to make-up group 14.

The solid tie lines Coryell shows between Hf-Th, Ta-Pa, and W-U would now be rendered in broken form.

If Coryell's table was mapped to a 32- or 18-column form, group 3 would presumably be shown as bifurcating after Y.

The circle around indium is possibly a typo(?): indium has two stable isotopes, In-113 (4.29%) & In-115 (95.71%)... actually, In-155 has a half-life of 4.4x10¹⁴ years."


Top of Page

---

Year:  1952

PT id = 988, Type = formulation

Hakala's Periodic Law in Mathematical Form

Reino Hakala published a paper, The Periodic Law in Mathematical Form, J.Phys.Chem., 1952, 56(2) 178-181. It is argued that: "Janet's [left-step] best meets these requirements".



Thanks to René for the tip!

Top of Page

---

Year:  1954

PT id = 1317, Type = formulation

New Periodic Table of the Elements Based on the Structure of the Atom

Tomkeieff SI, 1954, A New Periodic Table of the Elements Based on the Structure of the Atom, Chapman & Hall, London.

Thanks to René Vernon for the tip, who writes:

It is a helix wrapped on the surface of a cone. The shadow on the left is from the edge of my hand holding down the table; the shadow on the right is from the edge of a different book, again used to hold down the table into some semblance of flatness.

Mazurs said: "This is not a very successful table".

First, there is the cumbersome nature of a table on a cone, Secondly, see how the eight main group numbers at the top are sort of mushed into the 18 A and B series group numbers. This does not work well.

The colour scheme shows the dominant acid-base properties of the elements:

Dark blue — strong bases
Light blue — weak bases
Light red — weak acids
Dark red — strong acids
White — Inert gases

Since nonmetals never form basic oxides it is interesting to note that the (23) nonmetals fall on the right side of the table:

H He
B C N O F Ne
Si P S Cl Ar
Ge As Se Br Kr
Sb Te I Xe
Rn

[Water is amphoteric; hydrogen peroxide is weakly acid.]

While the underlined elements are sometimes called metalloids, it is has been known for over 100 years that metalloids predominately behave chemically like nonmetals.

Astatine would’ve been a nonmetal but for relativistic effects. Immediately following its production in 1940, early investigators considered it a metal.


Top of Page

---

Year:  1954

PT id = 1255, Type = formulation

Ephraim's Periodic Classification

Ephraim F 1954, Inorganic Chemistry, 6th ed., Oliver and Boyd, London (revised by PCL Thorne and ER Roberts)

René Vernon writes that items of interest include:

• The position of H "Which [according to Ephraim] is difficult to place in this table in a satisfactory manner", outside of the main body of the periodic table, "remote from both Li and F, well removed from C, and above He and the inert gases"
• The old school location of B-Al in Group IIIa
• C-Si belong to both Ti-Zr-Hf-Th and Ge-Sn-Pb


Top of Page

---

Year:  1956

PT id = 976, Type = formulation

Remy's Long Period Form Periodic Table

From H. Remy's 1956, Treatise on Inorganic Chemistry, Vol. 1, (Introduction and main groups of the periodic table), Elsevier, Amsterdam, p. 4, is what Remy calls a "Long-Period Form of the Natural System of the Elements".

This is a semi-lanthanide/actinide formulation, with Th-Pa-U shown as 6d metals, and the remaining actinides (Np, etc.) shown as transuranic counterparts to Pm, etc. The layout of Remy's table was based on ideas by Haissinsky in competition with Seaborg's formulation of 1945.

In the appendix there is a second "Table II" version of this formulation with shorter periods.



Thanks to René for the tip!

Top of Page

---

Year:  1956

PT id = 1009, Type = formulation

Walker & Curthoys' New periodic Table Based of Stability of Atomic Orbitals

By W. R. Walker and G. C. Curthoys, A new periodic table based on the energy sequence of atomic orbitals, J. Chem. Educ., 1956, 33 (2), p 69.

The abstract states:

"Since the theory of atomic and molecular orbitals has proven to be of such value in interpreting the data of inorganic chemistry, it is hoped that a new periodic table based on the energy sequence of atomic orbitals will be an aid to the further systematizing of chemical knowledge."



Thanks to René for the tip!

Top of Page

---

Year:  1957

PT id = 1079, Type = formulation

Laubengayer's Long Periodic Table

From A.W. Laubengayer, General Chemistry, revised ed., Holt, Reinhart and Winston, New York (1957).

René Vernon writes:

"In this busy table the author appears to show three of each of groups I to VII (e.g group I; group IA; group IB) and one group VIII, and one group 0, for a total of 23 groups and subgroups."


Top of Page

---

Year:  1958

PT id = 1148, Type = formulation

Landau & Lifshitz's Periodic System of Mendeleev

L.D. Landau & E.M. Lifshitz, Quantum Mechanics (Volume 3 of A Course of Theoretical Physics), pages 255-258. (Note: First published in English in 1958, the link is to the 1963 3rd ed. of the English version translated from Russian.)

René Vernon writes:

The authors discuss aspects of the periodic system of D I Mendeleev. The electron configurations of hydrogen & helium are briefly noted. This is followed by three tables setting out the electron configurations of the s, p, d & f elements.

Some extracts from the text follow:

"The elucidation of the nature of the periodic variation of properties, observed in the series of elements when they are placed in order of increasing atomic number, requires an examination of the peculiarities in the successive completion of the electron shells of atoms." (p. 252)

"Many properties of atoms (including the chemical properties of elements...) depend principally on the outer regions of the electron envelopes." (p. 254)

"The elements containing complete d and f shells (or not containing these shells at all) are called elements of the principal groups; those in which the filling up of these states is actually in progress are called elements of the intermediate groups. These groups of elements are conveniently considered separately." (p. 254)

"We see that the occupation of different states occurs very regularly in the series of elements of the principal groups: first the s states and then the p states are occupied for each principal quantum number n. The electron configurations of the ions of these elements are also regular (until electrons from the d and f shells are removed in the ionisation): each ion has the configuration corresponding to the preceding atom. Thus, the Mg⁺ ion has the configuration of the sodium atom, and the Mg⁺⁺ ion that of neon." (p. 255)

"Let us now turn to the elements of the intermediate groups. The filling up of the 3d, 4d, and 5d shells takes place in groups of elements called respectively the iron group, the palladium group and the platinum group. Table 4 gives those electron configurations and terms of the atoms in these groups that are known from experimental spectroscopic data. As is seen from this table, the d shells are filled up with considerably less regularity than the s and p shells in the atoms of elements of the principal groups. Here a characteristic feature is the 'competition' between the s and d states."

"This lack of regularity is observed in the terms of ions also: the electron configurations of the ions do not usually agree with those of the preceding atoms. For instance, the V+ ion has the configuration 3d4 (and not 3d24s2 like titanium) ; the Fe+ ion has 3d⁶4s¹ (instead of 3d⁵4s² as in manganese)."

"A similar situation occurs in the filling up of the 4f shell; this takes place in the series of elements known as the rare earths. † The filling up of the 4f shell also occurs in a slightly irregular manner characterised by the 'competition' between 4f, 5d and 6s states."

"† In books on chemistry, lutetium is also usually placed with the rare-earth elements. This, however, is incorrect, since the 4f shell is complete in lutetium; it must therefore be placed in the platinum group."

"The last group of intermediate elements begins with actinium. In this group the 6d and 5f shells are filled, similarly to what happens in the group of rare-earth elements." (p. 256–257)

The authors exclude lanthanum from the rare earths since the 4f shell has not started filling. Yet actinium and thorium are included by them with what we now call the actinoids even though these two metals have no f electrons. No explanation is provided for this puzzling lack of consistency with their categories.







René Vernon writes: I have joined up their one note and three tables. (Curium was the last known element at their time of writing; transcurium elements are shown in parentheses.):


Top of Page

---

Year:  1958

PT id = 1263, Type = formulation

Weaver & Foster's Laminar Chart of the Elements

Weaver EC & Foster LS 1960, Chemistry For Our Times. 3rd ed., McGraw-Hill, New York, p. 382

René Vernon writes:

An earlier version of this table appeared in JChemEd in 1949. The authors then wrote:

"It is apparently difficult to give a proper idea of electronic configuration in two dimensions without spreading out vertically or horizontally, and thereby sacrificing the order of atomic number, or compactness, or both. In three dimensions it is entirely feasible, but the first reaction is to discard three dimensions as too awkward. The laminar chart here proposed seems to the authors to possess the advantages of both the two dimensional and three dimensional charts and to have none of their disadvantages.

"A minor feature of the table, introduced for reasons of expediency, is the artificial break between the first and the second main shell. Use is made of this space to print the traditional group headings, I A, III A, IVB, etc., which are firmly entrenched in the literature, and still find active use as classifying labels. Other objects in making the artificial break were to minimize the resemblance between hydrogen and the alkali metals and to emphasize helium's character as an inert gas (completed 1s subshell), rather than, as might otherwise be supposed, a member of the alkaline earth family.

"CONTOUR LAMINAR TABLE

"By another modification, constructing the Periodic Chart in the form of contour laminae, it is possible to represent actual energy levels without the necessity of referring to auxiliary tables. This is done by proportioning the rises between each subshell to correspond to the Pauling energy diagram. Thus, although the subshells having the same principal quantum number will be on the same contour lamina, they will not be on the same planar level. The recognition of these contour laminae is facilitated by the use of a different color for each one. A table of this type will then be more physically correct than the previous laminar models, and it is a question as to which form has the most practical utility.

"We believe that the laminar periodic tables, in either the original or a modified form, will greatly facilitate systematic teaching of the properties of the chemical elements. Students indoctrinated with the new system cannot fail to obtain a clearer and more lasting conception of the fundamental principles of inorganic chemistry."

Note the 4f and 5f series have been split into dyads of seven apiece. This is consistent with Shchukarev (1974, p. 118) who wrote that the filling sequence among the 4f metals is periodic, with two periods. Thus, after the occurrence of a half-full 4f subshell at europium and gadolinium, the filling sequence repeats with the occurrence of a full subshell at ytterbium and lutetium (Rokhlin 2003, pp. 4–5). A similar, but weaker, periodicity (Wiberg 2001, pp. 1643–1645) is seen in the actinoids, with a half-full 5f subshell at americium and curium, and a full subshell at nobelium and lawrencium.

Note that Zn, Cd, Lu and Hg have no electron numbers above them since the underlying shells were filled at Cu, Cd, Yb, and Au respectively.

• Rokhlin LL 2002, Magnesium Alloys Containing Rare Earth Metals: Structure and Properties, Taylor & Francis, London
• Shchukarev SA 1974, Neorganicheskaya khimiya, vol. 2. Vysshaya Shkola, Moscow (in Russian)
• Weaver EC & Foster LS 1960, Chemistry For Our Times. 3rd ed., McGraw-Hill, New York, p. 382
• Wiberg N 2001, Inorganic Chemistry, Academic Press, San Diego
• Wrigley AN, Mast WC & McCutcheon TP 1949, A laminar form of the periodic table, Part I, Journal of Chemical Education, 26(4), 216
• —— A laminar form of the periodic table, Part II, Journal of Chemical Education, 26(5), 248



Top of Page

---

Year:  1960

PT id = 1012, Type = formulation

International Rectifier Corporation Periodic Table

International Rectifier Corporation was an American power management technology company manufacturing analog and mixed-signal ICs, advanced circuit devices, integrated power systems, and high-performance integrated components for computing. It is now part of Infineon Technologies.

The periodic table below was produced in the late 1950s to early 1960s. The earliest version we can find on the web dates from 1960.

Click to enlarge.



Thanks to René for the tip!

Top of Page

---

Year:  1962

PT id = 1177, Type = formulation

Scott & Kendal Periodic Table

René Vernon shows an extract from Scott E.C. & Kendal F.A., The Nature of Atoms & Molecules: A General Chemistry. Harper & Row, New York, 1962 pp 385, categorising the metals.

Rather than providing a holistic treatment of the nonmetals, the authors take a group-by-group approach.

Items of interest: Al over Sc; the split between groups 3 and 3; and the inclusion of Pt with the soft metals.

On the right is my add-on for the nonmetals, plus extracts from the literature speaking to the analogies between the four metal and four nonmetal categories.

Click to enlarge


Top of Page

---

Year:  1963

PT id = 990, Type = formulation

Bedreag's Système Physique Des Éléments

From Le Journal De Physique Et Le Radium, 24, pp27 (1963).

After a short historical account of the evolution of the periodic system Bedreag analyses some properties of various groups of elements: density, spectra, ionic radii, ionization potentials and so on, arguments are given in favour of the division of the transuranic elements into "uranides" and "curides".



Thanks to René for the tip!

Top of Page

---

Year:  1963

PT id = 1249, Type = formulation

Hutton's Periodic Table of The Elements

Hutton, K 1963, Chemistry: The Conquest of Materials, Penguin Books. Harmondsworth, Middlesex, pp. 38–39

René Vernon writes:

"Hutton shows:

• H over F
• the lanthanides under Y
• fifteen uranides under W (Hutton says they have, "properties increasingly similar to one another".)

Hutton refers to group 6A (Cr, Mo, W) as the "steel hardening" elements".


Top of Page

---

Year:  1964

PT id = 1006, Type = formulation

Haward's Periodic Table

Roger Hayward created this periodic table for the book: Pauling & Hayward, p4, The Architecture of Molecules, W H Freeman and Company, San Francisco (1964).

From The Pauling Blog:

"By the end of the 1950s, Roger Hayward had retired from his professional work as an architect at the same time that his career as an illustrator was reaching its peak. Hayward signed a contract in the early 1960s that helped to solidify his position as a technical artist. The contract that Hayward signed was with W.H. Freeman & Company, a San Francisco-based publishing house that rose out of relative obscurity primarily by publishing Linus Pauling's hugely popular textbook, General Chemistry."



Thanks to René for the tip!

Top of Page

---

Year:  1964

PT id = 1271, Type = formulation

Ternström's Periodic Table

Ref: A Periodic Table, Torolf Ternström, J. Chem. Educ. 1964, 41, 4, 190

René Vernon writes:

"Ternström gives us a triple-combo table drawing on the advantages of:

• the complete block system according to Werner (1905)
• a horizontal Bohr line-system according to Spedding (1951)

The outcome resembles the left step form of Janet (1928).

Some interesting features of Ternström's formulation are:

• a period 0 containing the neutrino and neutron
• element number "00" for "v" suggests the neutrino has neither nuclear charge nor mass while "0" for Nn implies no nuclear charge
• regular period lengths of 2-2-8-8-18-18-32-32
• hydrogen has no direct relationship with a group, only secondary relationships with groups A1 and A7
• germanium, a semiconductor, is counted as a metal
• all groups numbered, where A = representative; B = transition
• C = Ln/An; analogous "transition" groups in the d-block (B8) and the f-block (C6)
• double periodicity among the Ln and An; and
• 25 columns wide i.e 18 + 32 = 50/2 = 25"


Top of Page

---

Year:  1966

PT id = 1314, Type = formulation

Tottle's Periodic Table

Tottle CR 1974, The Science of Engineering Materials, reprint of 1966 ed., Heinemann Educational Books, London, p. 20

René Vernon writes:

I was drawn to the attached periodic table by the strange-looking arrangement of dividing lines, one "full" and one dashed, in the p-block.

Semimetals

Ge, As, Se, Sn, Sb, Te, Bi and Po are shown as semi-metals. Tottle does not explain the basis for this division.

Showing Sn as a semi-metal or metalloid is dubious. Sure, white-Sn becomes gray-Sn at a temperature of below 13.2 °C but even here it has the electronic band structure of a semi-metal.

The same can be said for Po which has electronic band structure of a true metal, unlike the situation in As, Sb and Bi, all of which have electronic band structures of semi-metals.

Metals & Nonmetals

Starting with H, note the left to right path of the full dividing line between metals and nonmetals is continuous, except for the unique break above Be, presumably to show that there is no element above Be. This is actually not well thought-out since the metallic or nonmetallic status of the IIA elements is not then clarified.

Tottle is further interesting since, as well as referring to metals and nonmetals in the periodic table sense he later includes a chapter on Metals and alloys, and a chapter on Non-metallic materials. Some examples given by him of non-metallic materials are alumina, magnesia, graphite, beryllia, titanium carbide, glass, rubber, nylon and wood. So, he here is mixing nonmetallic elements and nonmetallic materials (which is fine).

Tottle gets into trouble in his chapter on Metals and alloys, since he includes some discussion on interstitial solid solutions, such as cementite Fe₃C, which is an insulator, and intermetallic compounds, which appears fine on the surface, until one realises that some intermetallic compounds are semiconductors, such as FeGa₃, RuGa₃, and IrGa₃. I have never heard of semiconducting or insulating metals or alloys.


Top of Page

---

Year:  1966

PT id = 1265, Type = formulation review 3D

Rare Earth Pop Out Periodic Table

From Rare Earths, The Fraternal Elements by Karl A. Gschneidner Jr., United States Atomic Energy Commission Division of Technical Information Library of Congress Catalog Card Number: 65-60546 1964; 1966 (Rev.)

There is an interesting point made in the text concerning the term "Rare Earths":

"The name rare earths is actually a misnomer for these elements are neither rare nor earths. They are metals, and they are quite abundant. Cerium, which is the most abundant, ranks 28th in the abundances of the naturally occurring elements and is more plentiful than beryllium, cobalt, germanium, lead, tin, or uranium. The least abundant naturally occurring rare earth, thulium, is more plentiful than cadmium, gold, iodine, mercury, platinum, or silver. Indeed, 25% of the elements are scarcer than thulium."



Thanks to René for the tip!

Top of Page

---

Year:  1969

PT id = 1308, Type = review formulation

100 Years of the Periodic Law of Chemical Elements

A Soviet Union publication in Russian celebrating Medeleeve's seminal work of 1869: 100 Years of the Periodic Law of Chemical Elements, X Centennial (Jubilee) Mendeleev Congress. The work is the product of 23 Authors. (Thanks to Ann E. Robinson, René Vernon & Valery Tsimmerman for the info.)






Top of Page

---

Year:  1969

PT id = 1146, Type = review

Mendeleevian Conference, Periodicity and Symmetries in the Elementary Structure of Matter

Atti del Convegno mendeleeviano : periodicità e simmetrie nella struttura elementare della materia : Torino-Roma, 15-21 settembre 1969 / [editor M. Verde] Torino : Accademia delle Scienze di Torino ; Roma : Accademia Nazionale dei Lincei, 1971 VIII, 460 p.

Google Translate: Proceedings of the Mendeleevian Conference: periodicity and symmetries in the elementary structure of matter: Turin-Rome, 15-21 September 1969 / [editor M. Verde] Turin: Turin Academy of Sciences; Rome: National Academy of the Lincei, 1971 VIII, 460 p.

From the Internet Archive, the scanned book. Papers are in Italian & English.

For the 100th Anniversary of Mendeleev's iconic periodic table, a conference was held to look at (review) the elementary structure of matter. The 1960s saw huge developments in particle physics, including the theory of quarks. Papers were presented by many notable scientists including John Archibald Wheeler and the Nobel laureates: Emilio Segrè & Murray Gell-Mann.






Thanks to René for the tip!

Top of Page

---

Year:  1969

PT id = 1010, Type = formulation

Dash's Quantum Table of the Periodic System of Elements

Harriman H. Dash, A quantum table of the periodic system of elements, International Journal of Quantum Chemistry, vol. 3, no. S3A, supplement: Proceedings of the International Symposium on Atomic, Molecular, and Solid?state Theory and Quantum Biology, 13/18 January 1969, pp. 335–340.

The abstract reads:

"The shortcomings of the long form of the periodic table of the chemical elements and the evident need for updating this format are briefly reviewed. To the question 'what format?' quantum physics provides an unequivocal answer. The foundations for the design of a quantum table are outlined. These are based on the principal quantum number as derived from the Schroedinger wave equation, the law of second order constant energy differences, and the coulomb–momentum interaction. These concepts are all combined into a single format which optimally and explicitly relates periodicity to atomic structure and the physical, chemical, and biological properties of the elements. This relationship emphasizes the unity and universality of all sciences."



Thanks to René for the tip!

Top of Page

---

Year:  1969

PT id = 1270, Type = formulation data misc

Seel-Klechkovskii Version of Madelung's Rule for Orbital Filling

Seel F., Bild der Wissenschaft, 6, 44 (1969), a monthly popular scientific journal.

• Klechkovskii VM, Dokl. Akad. Nauk. SSSR, 135. 855 (1980). [In Russian]
• Klechkovskii VM, Zh. Eksperim. i. Teoret. Fiz., 41. 465 (1961). [In Russian]



Thanks to René for the tip!

Top of Page

---

Year:  1969

PT id = 1273, Type = formulation data

Martin's Crystal Structure Periodic Table

Ref: Martin JW 1969, Elementary Science of Metals, Wykeham Publications, London

René Vernon writes:

Note the unusual placement of La-Ac in two places, under Y and before Ce-Th. On another aspect, Martin writes:

"The non-metals, which occupy the top right-hand corner of the Periodic Table... form about one-sixth of all elements, and they are characterized by having melting-points and boiling points below about 500°C, and by having their solid and liquid phases not conducting electricity. About two-thirds of all elements are metals, and a further one sixth have properties intermediate between those of metals and non-metals."

His approach to the question of which elements are metals and non-metals, and which are intermediate may be the most useful "rough-and-ready" rubric I've seen. It is remarkable for its use of four criteria.

Perhaps we can then parse the elements as follows

Non-metals (16) = 15.5%
Fluids: H, N, O, F, Cl, Br; He, Ne, Ar, Kr, Xe, Rn 2
Solids: P, S, Se*, I

Intermediate (16) = 15.5%
Metalloids: B, Si, Ge, As, Sb, Te
Near metalloids: C, At 3
Sub-metalloids: Al, Ga, In, Tl; Sn, Pb; Bi; Po

Metals (71) = 68.9%
Be,^ Zn^
All the rest

^ Borderline intermediate

Dingle (2017, The Elements: An Encyclopedic Tour of the Periodic Table, Quad Books, Brighton, p. 101) puts the situation this way:

"...the gap between the two extremes [of metals and nonmetals] is bridged... by the poor metals, and... the metalloids – which, perhaps by the same token, might collectively be renamed the poor non-metals.”



Redrawn by Vernon:



Thanks to René for the tip!

Top of Page

---

Year:  1970

PT id = 1007, Type = formulation

Pauling's "General Chemistry" Periodic Table

From Linus Pauling's General Chemistry (3rd Ed.). Notice that the noble gases apear twice, at the beginning and the end of each period.



Thanks to René for the tip!

Top of Page

---

Year:  1971

PT id = 672, Type = formulation

Clark, John O. E. Periodic Table

Thanks to René Vernon who found this formulation, and writes:

"Here's a strange table I found in the following book: Clark Jonh O.E. 1982, Chemistry (The Hamlyn Publishing Group, Feltham, Middlesex) ISBN 0600001245. The colour coding is exasperating. The way the table is laid out is bizarre. The copy I have is a reprint of the original 1971 edition so I have to wonder if the graphic designer was drawing inspiration from the trippy 60s."



Top of Page

---

Year:  1974

PT id = 1058, Type = formulation spiral

Mazurs' Redrawing of Stedman's Formulation

An spiral formulation by Mazurs, cited as being after Janet (1928). However, it is actually, it is after Stedman (1947).

In an article Bull. Hist. Chem., VOLUME 34, Number 2 (2009) O.T. Benfey writes:

"After we had developed our own [Periodic Snail] spiral design, we found that E. G. Mazurs had published a spiral with a separate protrusion for the lanthanides which, under the image, he misleadingly ascribed to Charles Janet in 1928, the same year that Janet had published a simple circular form also shown by Mazurs. The Mazurs diagram with the lanthanide protrusion was reprinted in [the journal] Chemistry. However, [Philip] Stewart informed me that the Mazurs figure bears no resemblance to the Janet diagram he indicated nor to any other of his designs. Detailed references given a few pages later by Mazurs suggested correctly that the spiral derives from Stedman and is so identified and depicted by van Spronsen. The Mazurs diagram is a mirror image of the Stedman spiral, updated to include elements discovered since 1947." [For references, see the article.]"

Mazurs (p. 77) writes:

"Subtype IIIA3–1a Helix on a modified cone. The transition and inner transition elements have special revolutions in the form of loops. This table, originated by Stedman in 1947 is not a successful one."



Thanks to René for the tip and information!

Top of Page

---

Year:  1982

PT id = 49, Type = formulation 3D

Cement Chemist's Periodic Cube

Periodic table designed in the style of a cube by J. Francis Young, Professor of Civil and Ceramic Engineering, University of Illinois. This table was published by Instruments for Research and Industry and includes instructions for assembly into a 3-D model.

More information, including high resolution files, at the Science History Institute.



Thanks to René Vernon for the tip!

Top of Page

---

Year:  1983

PT id = 50, Type = formulation 3D

Periodic Pyramid

Periodic table designed in the style of a pyramid by Charles E. Gragg. This table was published by Instruments for Research and Industry and includes instructions for assembly into a 3-D model.

More information, including high resolution files, at the Science History Institute.



Thanks to René Vernon for the tip!

Top of Page

---

Year:  1984

PT id = 1258, Type = formulation

Cherkesov: Two Periodic Tables

Cherkesov AI 1984, Ionization energy of 1-6 p-electrons and formation enthalpies of lutetium and lawrencium halides. Position of these elements in Periodic system, Radiokhimiya, vol. 26, no. 1, p. 53?60 (in Russian), https://inis.iaea.org/search/search.aspx?orig_q=RN:16012913

René Vernon writes:

"Two Russian offerings, the first is Mendeleev style, including He over Be and the integration of the Ln and An into the main body of the table.

"The second is the first time I have seen a genuine right step table, albeit at the expense of the numbers going backwards, and the non-intuitive group numbering scheme. Bonus marks for out-of-the box thinking."




Top of Page

---

Year:  1987

PT id = 1039, Type = formulation

Step-Pyramid Form of the Periodic Chart

By Bill (William) Jensen, a Step-Pyramid form of the periodic chart.

This formulation is an updated version of the charts by Thomsen (1895) and Bohr (1922) with more elements, including placeholders up to 118, electronic configuration lables, etc. Read more on the Science History Institute website.



Thanks to René for the tip!

Top of Page

---

Year:  1987

PT id = 1115, Type = formulation data

Variation of Orbital Radii with Atomic Number

From Jour. Fac. Sci., Hokkaido Univ., Ser. IV. vol. 22, no. 2, Aug., 1987, pp. 357-385, The Connection Between the Properties of Elements and Compounds; Mineralogical-Crystallochemical Classification of Elements by Alexander A. Godovikov & Yu Hariya.

The analyses of the variations of the orbital atomic radii values (r_orb) with the increase of the atomic number (Z) allow establishment of the following recurring regularities of their change:

Click image below to enlarge:



Thanks to René for the tip!

Top of Page

---

Year:  1987

PT id = 1116, Type = formulation data

Mineralogical-Crystallochemical Classification of Elements

From Jour. Fac. Sci., Hokkaido Univ., Ser. IV. vol. 22, no. 2, Aug., 1987, pp. 357-385, The Connection Between the Properties of Elements and Compounds; Mineralogical-Crystallochemical Classification of Elements by Alexander A. Godovikov & Yu Hariya.

Any mineralogical-crystallochemical classification of elements must provide answers to the following queries:

1. Which type of compounds certain elements will prefer to form under given conditions of mineral genesis (elementary substance, chalcogenide, oxide, oxysalt, etc.,)
2. Whether the element will play a role of a cation or anion of a certain valency
3. Which type of chemical bond the resulting mineral compound will have

Click images below to enlarge:





Thanks to René for the tip!

Top of Page

---

Year:  1992

PT id = 1091, Type = formulation 3D

Magarshak & Malinsky's Three Dimensional Periodic Table

Y. Magarshak & J. Malinsky's Three Dimensional Periodic Table from Nature, 360, 114-115 (1992).

M&M say:

"We believe that our three dimensional representation is a useful tool for visualizing properties of chemical elements and is in complete accord with quantum mechanics."



Thanks to René for the tip!

Top of Page

---

Year:  1993

PT id = 1268, Type = formulation misc data

Huheey's Version of The Madelung Rule (For Orbital Filling)

Huheey, J.E., Keiter, E.A., Keiter, R.L.: Inorganic Chemistry: Principles of Structure and Reactivity. 4th edn. HarperCollins College Publishers (1993), p. 22

René Vernon comments: "A peculiar depiction of the Madelung Rule order of filling diagram."



Top of Page

---

Year:  1994

PT id = 1159, Type = formulation

Treplow's Periodic Table of The Atoms

R.S. Treplow, J. Chem. Educ. 1994, 71, 12, 1007: The Periodic Table of Atoms: Arranging the Elements by a Different Set of Rules.

"Although periodic tables differ greatly in their appearance, examination shows they are all designed according to a common set of conventions. This paper reviews those conventions and asks how the table would look under a different set of rules."

Ground-state multiplicity vs. atomic number for elements 1 to 103. Subblocks are labeled S, P, D & F. Lines connecting the dots show the "ideal" pattern. Atoms not on the lines are "nonideal" (where ideal refers to Madelung's rule):





Thanks to René Vernon for his help.

Top of Page

---

Year:  1995

PT id = 1292, Type = formulation spiral

Considine's Polar Periodic Table

From: Considine DM (ed.) 1995, Van Nostrand’s Encyclopedia of Science, 8th ed. New York, p. 2376

René Vernon writes:

"A nice design but of quite limited practical utility for quick reference or detailed chemical analysis."


Top of Page

---

Year:  1995

PT id = 1130, Type = formulation

Klein's Periodic Table of The Elements

Klein DJ, Similarity and Dissimilarity in Posets, Journal of Mathematical Chemistry, 18(2), 321–348 (342) (1995)

The relevance of partially ordered sets (or posets) in a wide diversity of contexts in chemistry is emphasized, and the utility of distance functions (or metrics) on such posets is noted. First a notion of "scale similarity" is introduced to make comparisons within certain so-called "scaled" posets, for which there is formulated natural "comparators", which in turn lead to associated distance functions. Beyond taking note of several chemically relevant examples of these "scaled" posets and their consequent associated similarity measures, a second chemically relevant class of so-called "shifted" posets is similarly developed, with examples. Even further extension of some aspects of the current approach is indicated, and finally the multi-posetic character of chemical periodic law is suggested.



Thanks to René for the tip!

Top of Page

---

Year:  2000

PT id = 1240, Type = formulation data

Sneath's Dendtogram

Sneath, P., Numerical Classification of the Chemical Elements and Its Relation to the Periodic System. Foundations of Chemistry 2, 237–263 (2000).

Abstract: "A numerical classification was performed on 69 elements with 54 chemical and physicochemical properties... Only 15 properties were scorable for the noble gases, but despite the paucity of properties reflecting chemical reactivity, analysis of the 69 elements on these properties still showed the major features seen from the full set."

Sneath writes:

"The UPGMA tree shows three major clusters at the 70% similarity level:

1. Hydrogen, noble gases, reactive nonmetals and halogens.
2. A large cluster of less reactive metals and metalloids, with a few nonmetals.
3. A cluster of highly reactive metals.

These major clusters are almost consistent with the blocks based on electron shells. The first cluster belongs to the p-block plus hydrogen. The second belongs to the d-block together with a few p-block elements. The third consists of the s-block plus aluminum from the p-block.

Cluster 1: There are three subclusters. 1a. This contains hydrogen and the noble gases."



Thanks to René for the tip!

Top of Page

---

Year:  2001

PT id = 1322, Type = review misc formulation

Oliver Sacks, Uncle Tungsten: Memories of Tungsten of a Chemical Beyond

René Vernon writes:

On the paperback cover of Oliver Sack's Uncle Tungsten (below) the periodic table shows a 16–wide set of elements at its base. This is quite unusual since this set is normally shown as being 15— or 14— elements wide. See, for example, the table found on the site of the International Union of Pure & Applied Chemistry which shows a 15–wide set of elements at its base.

It looks like the second pair are La and Ac, but what then are two immediately preceding elements?

I suspect they are probably the alkaline earth metals, Ba and Ra. This may be an homage to Mr Rare Earth^ aka Karl A. Gschneidner Jr (1930–2016), who wrote that:

...since Ba has a 4f⁰6s² configuration, these three elements are the first (Ba), mid (Eu), and end (Yb) members of the divalent 4f transition series.

The notion of 4f⁰ is not unprecedented; the IUPAC periodic table, with its 15-wide f-block presumably implies La as 4f⁰ 5d¹ 6s².

There is some good chemistry going on here, given the pronounced similarities between Ba and the lanthanides, and the alkaline earth metals generally with about 20 properties involved:

• Most of the physical properties of Eu and Yb, "such as the atomic volumes, metallic radii, melting and boiling points, heats of sublimation, compressibilities, and coefficients of expansion are more like those of the alkaline-earth metals, Ca, Sr, and Ba, than those of the rare-earth metals" (Pauling 1960, p. 418; Gschneidner 1964, p. 286).
• Liquid ammonia dissolves certain alkali, alkaline earth, and Ln metals, and... combines with them to form solid compounds. Those metals whose compound-forming ability has been confirmed are Li, Ca, Sr, Ba, Eu and Yb. (Mammano (1970, p. 367)
• The lanthanides are sometimes regarded as trivalent versions of the alkaline earth metals (Evans 1982).
• The electron configurations of lanthanide cations are similar to those of alkaline earth metal cations, as the inner f- orbitals are largely or completely unavailable for bond formation; (Choppin & Rizkalla 1994)
• The lanthanide trivalent cations are essentially spherical and present an environment very similar to alkali and alkaline earth ions towards complex formation... the standard electrode potentials for the lanthanides have similar values and are comparable with the redox potentials of alkaline earth metals (Sastri et al. 2003)
• Ba-Eu-Yb have cubic crystalline structures whereas the rest of the Ln are hexagonal, or rhombohedral in the case of Sm (Russell & Lee 2005)
• There is a close alloying similarity between the lanthanides and Ca, Sr and Ba (Artini 2007)
• Lanthanides are effective mimics of calcium and can stimulate or inhibit the function of calcium-binding proteins (Brayshaw 2019)
• Lanthanide cations can substitute for Ca2+ and Sr2+ cations in host materials for solid state lasers (Ikesue 2013)
• There is a knight’s move relationship between Ca and La:
  • The ionic radius of Ca²⁺ is 114 pm; that of La³⁺ is 117 pm
  • The similarity in sizes means La³⁺ will compete with Ca²⁺ in the human body, and usually win on account of having a higher valence for roughly the same hydrated radius
  • The basicity of La₂O₃ is almost on par with CaO₂ Freshly prepared La2O3 added to water reacts with such vigour that it can be quenched like burnt lime (CaO)
  • The electronegativity of Ca is 1.0; that of La is 1.1.

Kudos to Oliver.

^Pecharsky 2016

Sources

• Artini C (ed.) 2017, Alloys and Intermetallic Compounds: From Modeling to Engineering, CRC Press, Boca Raton, p. 92
• Brayshaw et al. 2019, Lanthanides compete with calcium for binding to cadherins and inhibit cadherin-mediated cell adhesion, Metallomics, vol. 11, no. 5, 2019, pp. 914–924
• Choppin GR & Rizkalla EN 1994, Solution chemistry of actinides and lanthanides, Handbook on the Physics and Chemistry of Rare Earths, pp. 559–590(560)
• Evans WJ 1982, Recent advances in the low valent approach to f-element organometallic chemistry, in McCarthy GJ, Silber HB and Rhyne JJ (eds), The Rare Earths in Modern Science and Technology, vol. 3, Plenum Press, New York, pp. 61–70(62)
• Gschneidner KA 1965, in Seitz F & Turnbull D (eds), Solid State Physics, vol. 16, Academic Press, New York, p. 286
• Ikesue A, Aung YL, Lupei V 2013, Ceramic Lasers, Cambridge University Press, Cambridge, pp. 26, 28
• Mammano N 1970, Solid metal ammonia compounds, in Metal–Ammonia Solutions, Proceedings of an International Conference on the Nature of Metal–Ammonia Solutions: Colloque Weyl II, pp. 367-393 (367), https://doi.org/10.1016/B978-0-408-70122-8.50030-4
• Pauling L 1960, The Nature of the Chemical Bond, 3rd ed., Cornell University Press, Ithaca, p. 418
• Pecharsky V 2016, Karl A. Gschneidner Jr (1930–2016), Nature Materials, vol. 15, no. 1059, https://doi.org/10.1038/nmat4751
• Russell AM & Lee KL 2005, Structure-property relations in nonferrous metals, John Wiley & Sons, Hoboken, inside cover
• Sastri et al. 2003, Modern Aspects of Rare Earths and their Complexes, Elsevier, Amsterdam, pp. 377, 878



Top of Page

---

Year:  2003

PT id = 1082, Type = formulation 3D

Two-Amphitheater Pyramid Periodic Table

From Chemical Education Journal (CEJ), Vol. 7, No. 2

A Novel Way of Visualization of the Periodic Table of the Elements by Alaa El-Deen Ali Mohamed, Alexandria University, Egypt.

The author writes:

"New form of the periodic table of the elements is given in this paper. This form can be seen as two amphitheater pyramids facing each other. The cubes that meet are s-elements (interior) then the p-elements then d-elements and the f-elements at last (exterior). The table can be represented by X-, Y- and Z-axes, where the Z-axis gives the number of the period that the element occupies. The table can be modeled by colored cubes helping in introducing the periodic table to the pupils early in the primary education."



Thanks to René for the tip!

Top of Page

---

Year:  2003

PT id = 1150, Type = formulation data

Stable Isotopes, Periodic Table of

From Boeyens, JCA 2003, J. Radioanal. Nucl. Chem., 257, 33 a periodic table of the 264 stable isotopes arranged as an 11 x 24 matrix.

Click the image to enlarge:



Thanks to René for the tip!

Top of Page

---

Year:  2004

PT id = 1096, Type = misc

Classroom Kids Periodic Table

From a paper by René Vernon, a drawing of the elements as classroom personality kids, drawing by Richard Thompson 1957-2016.

From a National Geographic coffee table book: Curt Suplee, The New Everyday Science Explained, National Geographic Society, Washington DC, p. 130 (2004). The undated credit is given to Richard Thompson.

• Sodium is actively practicing a "salt-formation" passing play with corrosive chlorine, who devours the delivery.
• Potassium, magnesium and barium are having an active metal huddle.
• The two hydrogens are hot desking.
• Iron is reading a weightlifting workout book.
• Platinum introduces gold to iridium, all three being noble metals.
• Lead, as a heavy frontier metal, is playing air guitar.
• Carbon is having a link up with frontier metal silver (masquerading as a transition metal); an unidentified frontier metal; and two "other" nonmetals.
• Silicon, as a metalloid and a semiconductor, is catching up on an assignment.
• Helium and neon, having each had a cup of chamomile tea during the break, are sleeping.



Top of Page

---

Year:  2005

PT id = 1242, Type = formulation

Rich's Periodic Chart Exposing Diagonal Relationships

Rich, R. L. (2005). Are Some Elements More Equal Than Others? Journal of Chemical Education, 82(12), 1761. doi:10.1021/ed082p1761.



Thanks to René for the tip!

Top of Page

---

Year:  2007

PT id = 1282, Type = formulation

Seeger-Quadbeck Periodic Table

Seeger-Quadbeck H-J 2007, World of the Elements Elements of the World, Wiley-VCH, Wienheim, inside cover.

René Vernon, who provided the graphic, writes:

"An example of a rarely seen 32-column table. The categorisation scheme is interesting.

• Hydrogen is a category of its own.
• The semimetals include selenium and astatine.
• There is no separate category for the halogen nonmetals.
• On page 100 the author refers to the inner occupation of the TM and Ln/An being particularly clear."


Top of Page

---

Year:  2007

PT id = 778, Type = formulation data

Mechanical Engineer's Periodic Table

Avallone EA, Baumeister T & Sadegh AM (eds) 2007, Marks' Standard Handbook for Mechanical Engineers, 11th ed., McGraw-Hill, New York, p. 6-6. Click here for a larger version.

This mech eng PT has a couple of odd features: hydrogen is in Group 17 above fluorine and the lanthanides are split:



Thanks to René for the tip!

Top of Page

---

Year:  2007

PT id = 1021, Type = formulation 3D spiral

Bent & Weinhold's 2D/3D Periodic Tables

From a paper by Henry Bent & Frank Weinhold, J. Chem. Educ., 2007, 84, 7, 1145 and here. The authors write in the abstract:

"The periodic table epitomizes chemistry, and evolving representations of chemical periodicity should reflect the ongoing advances in chemical understanding. In this respect, the traditional Mendeleev-style table appears sub-optimal for describing a variety of important higher-order periodicity patterns that have become apparent in the post-Mendeleevian quantal era. In this paper we analyze the rigorous mathematical origins of chemical periodicity in terms of the quantal nodal features of atomic valence orbitals, and we propose a variety of alternative 2D/3D display symbols, tables, and models.":







Thanks to René for the tip!

Top of Page

---

Year:  2008

PT id = 1302, Type = formulation

Franklyn's Periodic Table

Franklyn writes on sciencemaddness.org: Electronic Orbital Periodicity Mendelevian grouping is only one possible organizational scheme, regardless of the schematic choice. A table is useful only to the extent that it provides easy reference to data and comparison. Most everyone who has considered arranging elements in tabular form has pondered what layout best serves the purpose. Below is a table I once made to determine the electronic shell and orbital structure of any element at a glance. Everything to the left and above the elements position indicates the complete full orbitals for those shells. Actually you can see the goup memebers run diagonally from upper left to lower right This arrangement shows that the progression of successive electrons is not straight forward with regard to placement within the atoms. The Mendelevian sequence begining with period 6 through the Lanthanides back to period 6 transition metals until Radon, continuing with period 7 ending with the first member of the Actinides, is as follows:

• shell 6, s orbital - Cesium, Barium (Cs, Ba)
• shell 5, d orbital - Lanthanum (La)
• shell 4, f orbital - Cerium to Lutecium (Ce, Pr, Nd, Pm, Sm, Eu, Gd, Tb, Dy, Ho, Er, Tm, Yb, Lu)
• shell 5, d orbital - Hafnium to Mercury (Hf, Ta, W, Re, Os, Ir, Pt, Au, Hg)
• shell 6, p orbital - Thallium to Radon (Tl, Pb, Bi, Po, At, Rn)
• shell 7, s orbital - Francium, Radium (Fr, Ra)
• shell 6, d orbital - Actinium (Ac)
• shell 5, f orbital - Thorium (Th)


Thanks to René Vernon for the tip!

Top of Page

---

Year:  2011

PT id = 1038, Type = formulation

Tresvyatskii's Periodic Table

Powder Metallurgy and Metal Ceramics, Vol. 49, Nos. 9-10, 2011:

The paper published below represents Tresvyatskii's fundamental study. It establishes the interrelation between the ionization potential and place of an element in the periodic table. Oxides with a certain composition may form only when an element is ionized to the needed degree. Hence, the ionization potential of elements is an important parameter that governs the formation of an oxide. In this regard, the dependence of the ionization potential on the place of an element in the periodic table is of paramount importance. The role of the ionization potential in the hightemperature chemistry of oxide compounds, which underlies modern oxide materials science, is especially significant. The paper is published in Tresvyatskii's original version.

René Vernon adds:

A depiction of the short-form table, showing some clever thinking:

• The reversal in atomic number order of Np to Am
• The return of the curides
• The placement of the Ln and the curides alongside the main table
• The assignment of the Ln and An to groups
• Triple periodicity among the Ln and heavy An


Top of Page

---

Year:  2017

PT id = 1120, Type = formulation data review

Restrepo's Similarity Landscape

Building Classes of Similar Chemical Elements from Binary Compounds and Their Stoichiometries by Guillermo Restrepo, Chapter 5 from: Elements Old and New: Discoveries, Developments, Challenges, and Environmental Implications p 95-110.

From the abstract:

Similarity is one of the key concepts of the periodic table, which was historically addressed by assessing the resemblance of chemical elements through that of their compounds. A contemporary approach to the similarity among elements is through quantum chemistry, based on the resemblance of the electronic properties of the atoms involved. In spite of having two approaches, the historical one has been almost abandoned and the quantum chemical oversimplified to free atoms, which are of little interest for chemistry. Here we show that a mathematical and computational historical approach yields well-known chemical similarities of chemical elements when studied through binary compounds and their stoichiometries; these similarities are also in agreement with quantum chemistry results for bound atoms. The results come from the analysis of 4,700 binary compounds of 94 chemical elements through the definition of neighbourhoods for every element that were contrasted producing similarity classes. The method detected classes of elements with different patterns on the periodic table, e.g. vertical similarities as in the alkali metals, horizontal ones as in the 4th-row platinum metals and mixed similarities as in the actinoids with some transition metals. We anticipate the methodology here presented to be a starting point for more temporal and even more detailed studies of the periodic table.



Thanks to René for the tip!

Top of Page

---

Year:  2018

PT id = 1202, Type = formulation

Beylkin's Periodic Table of The Elements

René Vernon writes: Beylkin's Periodic Table of The Elements has 4n² periods, where n = 2,3..., and shows symmetry, regularity, and elegance, more so than Janet's left step table.

Beylkin (an applied mathematician) writes:

"Let us take a continuous strip of paper and, on one side of the strip, write all the elements in the order of their atomic numbers. We then form a spiral with the strip such that the two most chemically distinct groups, the group of halogens (in which we include hydrogen) and the group of noble gases, are properly aligned. By flattening the strip on a plane and folding it in the middle, we obtain the new periodic table..."

Other features:

• H is over F, which is a smoother fit in terms of physicochemical trends down the group
• He is over Ne, which is a smoother fit etc
• group 3 has lanthanum in it
• the modern relationships Ti-Zr-Hf, V-Nb-Ta, Cr-Mo-W, and Mn-Tc-Re can still be traced
• the lanthanides and actinides are integrated into the main body of the table
• 15 lanthanides and 15 actinides(!)
• the old school arrangement of B-Al-Sc-Y-La can still be traced, as can the less smooth alternative B-Al-Sc-Y-Lu
• the 1s "block" starts at H; the s block proper at Li; p at B; d at Sc; f at Ce

There are four new(ish) groups: Ti-Zr-Ce-Th, V-Nb-Pr-Pa, Cr-Mo-Nd-U and Mn-Tc-Pm-Np. For the actinide elements of these groups, the resemblance of the earlier actinides to their lighter transition metal congeners is well known. For the lanthanide elements, Johansson et al. (2014) wrote a nice article about Ce and its cross-road position. For Pr, Nd, and Pm, all of these are known in multiple oxidations states (+2, +3, +4 excl. Pm, and +5 for Pr only), just as the transitions metals are so known.

• Beylkin G 2018, The periodic table of the elements with 4n2 n = 2,3... periods, https://arxiv.org/pdf/1901.02337.pdf
• Eric 2006, https://www.meta-synthesis.com/webbook/35_pt/pt_database.php?PT_id=20
• Johansson, B., Luo, W., Li, S. et al. 2014, Cerium; crystal structure and position in the periodic table. Sci Rep 4, 6398. https://doi.org/10.1038/srep06398
• Gregory Beylkin: https://en.wikipedia.org/wiki/Gregory_Beylkin


Top of Page

---

Year:  2018

PT id = 1261, Type = formulation

Kurushkin's 32-Column Periodic Table & Left-step Periodic Table United

Dr Mikhail V. Kurushkin, 32-column Periodic Table & Left-step Periodic Table United: https://bernalinstitute.com/events/bernal-seminar-by-dr-mikhail-v-kurushkin-itmo-universityrussia/

ABSTRACT
The pursuit of optimal representation of the Periodic Table has been a central topic of interest for chemists, physicists, philosophers and historians of science for decades (Leigh, 2009; Scerri, 2009). Should the Periodic Table of Chemical Elements first and foremost serve the needs of chemists as implied by its name? Or should it start from considerations of before quantum mechanics and thus be more appealing to physicists (Scerri, 2010, 2012b)? Is there a representation which overcomes this problem? The Periodic Table is from a fundamental point of view a graphic representation of periodicity as a phenomenon of nature. While the 32-column Periodic Table, popularized by Glenn T. Seaborg, is considered by chemists the most scientifically correct representation (Scerri, 2012a), physicists apparently prefer the Left-step Periodic Table above all (Scerri, 2005; Stewart, 2010). Alternatively, it is suggested that a rigorously fundamental representation of periodicity could only take the form of a spiral as, evidently, the abrupt periods of 2-D Periodic Tables contradict the gradual increase of atomic number, and the spiral representation reconciles this debate (Imyanitov, 2016). An optimal representation is eagerly sought after both for the needs of philosophy of chemistry and chemical education as their never-ending dialogue secures a thorough methodology of chemistry. The aim of the present work is to show that the 32-column Periodic Table and the Left-step Periodic Table can co-exist in mutual tolerance in a form of what Philip Stewart has already called Kurushkin’s Periodic Table (Kurushkin, 2017), Figure 1 below.

René Vernon writes:

"Kurushkin reminds us that the Janet left step table (with Sc-Y-Lu-Lr, and He over Be), and the version of the table with the s-elements on the right (also with Sc-Y-Lu-Lr, and He over Be) are interchangeable.

"For an earlier paywall version which includes a short video see:

Kurushkin M 2018, Building the periodic table based on the atomic structure, Journal of Chemical Education, vol. 94, no. 7, pp. 976–979, https://pubs.acs.org/doi/10.1021/acs.jchemed.7b00242

"Kurushkin’s interchangeable approach extends to tables with group 3 as either Sc-Y-La-Ac or Sc-Y-Lu-Lr. See Vernon's Yin Yang of The Periodic Table https://www.meta-synthesis.com/webbook/35_pt/pt_database.php?PT_id=1252"




Top of Page

---

Year:  2019

PT id = 1027, Type = formulation data

Chemical Bonds, Periodic Table of

The Max Planck Society (M-P-G, Max-Planck-Gesellschaft) has an article about the hidden structure of the periodic system.

Guillermo Restrepo, MPI for Mathematics in the Sciences:

"A periodic table of chemical bonds: Each of the 94 circles with chemical element symbols represents the bond that the respective element forms with an organic residue. The bonds are ordered according to how strongly they are polarized. Where there is a direct arrow connection, the order is clear: Bonds of hydrogen, for example, are more polarized than bonds of boron, phosphorus, and palladium. The same applies to rubidium in comparison to caesium, which has particularly low polarized bonds and is therefore at the bottom of the new periodic table. If there is no direct arrow between two elements, they may still be comparable – if there is a chain of arrows between them. For example, the bonds of oxygen are more polarized than the bonds of bromine. Bonds represented by the same colour have the same binding behaviour and belong to one of the 44 classes.":



Thanks to René for the tip!

Top of Page

---

Year:  2019

PT id = 1028, Type = formulation

Slightly Different Periodic Table

The Max Planck Society (M-P-G, Max-Planck-Gesellschaft) has an article about the hidden structure of the periodic system.

Guillermo Restrepo, MPI for Mathematics in the Sciences:

"A slightly different periodic table: The table of chemical elements, which goes back to Dmitri Mendeleev and Lothar Meyer, is just one example of how objects – in this case the chemical elements – can be organized in such a system. The researchers from Leipzig illustrate the general structure of a periodic table with this example: The black dots represent the objects ordered by the green arrows. Using a suitable criterion, the objects can be classified into groups (dashed lines) in which the red arrows create a sub-order":



Thanks to René for the tip!

Top of Page

---

Year:  2019

PT id = 1046, Type = formulation data

Group 3 of The Periodic Table

There are several ways in which the 'common/modern medium form' periodic table are shown with respect to the Group 3 elements and how the f-block is shown. Indeed, there is even some dispute about which elements constitute Group 3. There are three general approaches to showing Group 3:

• Sc, Y, La, Ac
• Sc, Y than a gap for the lanthanides & a gap for the actinides
• Sc, Y, Lu, Lr


(See Scerri's take and Thyssen's view on this matter.)

So, which one of the three options is 'better'?

The general feeling amongst the knowledgeable is that leaving a gap is not an option, so it comes down to:

Sc, Y, La, Ac     vs.     Sc, Y, Lu, Lr

René Vernon has looked as the properties of the potential Group 3 elements, including: densities, 1st ionisation energies, ionic radii, 3rd ionisation energies, melting points & electron affinity:



Figure 1 shows that a Z plot of the density values for Sc, Y, La, Lu Ac and Lr follows a smooth trendline.



Figure 2 shows that a Z plot of the first ionization energy values follows a smooth trendline.



Figure 3 shows that a Z plot of the 6-coordinate ionic radii for the subject elements bifurcates after Y into an -La-Ac tranche (R2 = 0.99) and a -Lu-Lr branch (0.61). The trendline for -La-Ac is smoother.



Figure 4 shows a Z plot of 3rd ionisation energy values bifurcating after Y into a -Lu-Lr tranche (R2 = 0.83) and a -La-Ac branch (0.98). The trendline for -La-Ac is smoother.



Figure 5 shows that a Z plot of the melting points bifurcates after Y into an -Lu-Lr (R2 = 0.72) tranche and a -La-Ac (0.71) branch. While the fit values for the two options are comparable, -Lu-Lr is preferred since Y and La show a greater departure from trend.



Figure 6 has a Z plot of electron affinity values bifurcating after Y into an -La-Ac tranche (R2 = 0.85) and a -Lu-Lr branch (0.99).[iii] The trendline supports Lu-Lr. The trend-lines by themselves are inconclusive: two show no difference; two support -La-Ac; two support -Lu-Lr.

Upon reviewing the data, René's comment is that: "The net result is that the two options seem inseparable" and he proposes that IUPAC adopt the following periodic table numbering system:



Professor Sir Martyn Poliakoff's [of the Periodic Videos YouTube channel & Nottiningham University] take on this matter:

Top of Page

---

Year:  2019

PT id = 1133, Type = formulation data

Vernon's Oxidation Number Periodic Table

René Vernon's periodic table showing oxidation number trends.

René writes:

• This table is based on two tables by Fernelius (1986), one of which is a portrait version of Bohr's 1922 table, and the second of which is a conventional table highlighting oxidation number trends in groups 4 to 10, and most of the p-block. Ref. Fernelius WC , 'Some reflections on the periodic table and its use', Journal of Chemical Education, vol. 63, no. 3, pp. 263–266 (1986).
• In my table, the transition metals are in groups 4 to 11. As per Mark's Leach's email: "...It's the 'incomplete d-subshell' that gives rise to properties such as: variable oxidation state, catalytic behaviour, d-orbital splitting and [thus] coloured ions/compounds."
• I've included oxidation number details for some elements. I've tried a different way of showing the composition of a bifurcated group 3, which is more in keeping with Bohr's table.
• The horizontal bar of the "T" is for Sc → Ti; the downward bar is for Y → Lu-Lr.
• Thus, Group 3 as Sc-Y-Lu-Lr could be called group 3T.
• La-Ac and Lu-Lr are duplicated in a greyed-out style to make it clearer where the lanthanides and actinides fit into the main body of the table.
• The inner transition metals are clearly delineated. Analogously to the transition metals they're all capable of forming ions with incomplete f sub-shells.
• The early actinides resemble the transition metals.

Click image to enlarge


Top of Page

---

Year:  2019

PT id = 1178, Type = data

Abundance by Atomic Number, Z

An article in De Gruyter Conversations: The Periodic Table & The Lanthanides by Simon Cotton has this interesting chart of elemental abundance with respect to 10⁶ atoms of Si.

The image source is http://upload.wikimedia.org/wikipedia/commons/0/09/Elemental_abundances.svg



Thanks to René Vernon for the tip.

Top of Page

---

Year:  2019

PT id = 1246, Type = misc element

Periodic Table of the Elements Coloring Book

Periodic Table of the Elements Coloring Book

Project managing and chemistry overseen by Yann Brouillette (Faculty, Chemistry, Dawson College). Element representations and cover by Dawson College Illustration & Design students (2nd year)* overseen by Meinert Hansen (Faculty, Illustration & Design, Dawson College).






Thanks to René for the tip!

Top of Page

---

Year:  2020

PT id = 1316, Type = formulation

Ziggurat Formulation

Thanks to René Vernon for finding this "Ziggurat" formulation (with a dash of Segrè Chart, upper left) on the RSC page for Oganesson:


Top of Page

---

Year:  2020

PT id = 1097, Type = data

Annotated Periodic Table

From René Vernon's paper, Vernon, R.E. Organising the metals and nonmetals. Found Chem (2020). https://doi.org/10.1007/s10698-020-09356-6 (in the supplementary material).

Click image to enlarge.





Top of Page

---

Year:  2020

PT id = 1114, Type = formulation data

Vernon's Periodic Table showing the Idealized Solid-State Electron Configurations of the Elements

René Vernon writes:

"I've attached a periodic table showing the solid-state electron configurations of the elements. Among other things, it provides a first order explanation as to why elements such as Ln (etc.) like the +3 oxidation state.

"The table includes two versions of the f-block, the first starting with La-Ac; the second with Ce-Th. The table with the first f-block version has 24 anomalies [with respect to Madelung's rule]; the table with the second f-block version has 10 anomalies.

"In the case of the Sc-Y-La-Ac form, I wonder if such a solid-state table is more relevant these days than a table based on gas phase configurations, which has about 20 anomalous configurations.

"Partly we use gas phase configurations since, as Eric Scerri mentioned to me elsewhere, configurations were first obtained (~100 years ago?) from spectroscopy, and this field primarily deals with gas phase atoms. That said, are gas phase configurations still so relevant these days – for this purpose – given the importance of solid-state physics?

"I've never been able to find a periodic table of solid-state electron configurations. Perhaps that has something to do with it? Then again, surely I'm not the first person to have drawn one of these?"

Click image below to enlarge:


Top of Page

---

Year:  2020

PT id = 1117, Type = formulation data

Correlation of Electron Affinity (F) with Elemental Orbital Radii (r_orb)

From Jour. Fac. Sci., Hokkaido Univ., Ser. IV. vol. 22, no. 2, Aug., 1987, pp. 357-385, The Connection Between the Properties of Elements and Compounds; Mineralogical-Crystallochemical Classification of Elements by Alexander A. Godovikov & Yu Hariya and expanded by René Vernon who writes.

René Vernon writes:

I was delighted to read about two properties that account for nearly everything seen in the periodic table.

Two properties
While researching double periodicity, I happened upon an obscure article, which simply correlates electron affinity with orbital radius, and in so doing reproduces the broad contours of the periodic table. Having never thought much about the value or significance of EA, and its absence of easily discernible trends, I was suitably astonished. The authors left out the Ln and An and stopped at Bi. They were sitting on a gold mine but provided no further analysis.

Development
I added the data up to Lr, updated the EA values, and have redrawn their graph. It is a thing of beauty and wonderment in its simplest sufficient complexity and its return on investment. I've appended 39 observations, covering all 103 elements.

Observations

• Very good correspondence with natural categories
• Largely linear trends seen along main groups; two switchbacks seen in group 13; also falloffs (6p sub-shell) seen in groups 14-17
• First row anomalies seen for Li (in amphoteric territory), Be (ditto), C (misaligned), N (in noble gas territory), O (misaligned), F (ditto) and He (ditto)
• For group 13, the whole group is anomalous, no doubt due to the scandide contraction impacting Ga and the double whammy of the lanthanide and 5d contraction impacting Tl
• Nitrogen was called a noble gas before the discovery of the real noble gases and appropriately enough falls into that territory


• Rn is metallic enough to show cationic behaviour and falls just outside of noble gas territory
• F and O are the most corrosive of the corrosive nonmetals
• The rest of the corrosive nonmetals (Cl, Br and I) are nicely distributed, across the border from F
• The rest of the simple and complex anions, funnily enough, comprise the intermediate nonmetals
• The metalloids are nicely aligned; Ge falls a little outside of the metalloid line, being still occasionally referred to as a metal; Sb, being the most metallic of the metalloids falls outside the border; At is inside; Po is just outside


• Pd is located among the nonmetals due to its absence of 5s electrons; see here
• The proximity of H to Pd is astonishing given the latter's capacity to adsorb the former
• The post-transition metals (PTM) form an "archipelago of amphoterism" bounded by transition metals: Ni and C to the west; Fe and Re to the south; V, Tc and W to the east; noble metals to the north
• Curiously, Zn, Cd, and Hg are collocated with Be, and distant from the PTM and the TM proper (aside from Mn)
• Zn is shown as amphoteric, which it is. Cd is shown as cationic but is not too far away from amphoteric territory; it does show amphoterism, reluctantly; Hg is shown as amphoteric which is the case, weakly, for HgO, as is the congener sulfide HgS, which forms anionic thiomercurates (such as Na2HgS2 and BaHgS3) in strongly basic solutions


• The ostensibly noble metals are nicely delineated; Ag is anomalous given its greater reactivity; Cu, as a coinage metal, is a little further away
• The proximity of Au and Pt to the halogen line is remarkable given the former's capacity to form monovalent anions
• The ferromagnetic metals (Fe-Co-Ni) form a nice line
• The TM from groups 4-12 form switchback patterns e.g. Ti-Zr and the switchback to Hf
• The refractory metals, Nb, Ta, Mo, W and Re are in a wedge formation


• Tc is the central element of the periodic table in terms of mean radius and EA values; V is close, Cr is a little further away
• Ti is just inside the basic cation line; while Ti(IV) is amphoteric, Ti3+ is ionic
• Sc-Y-La shows a main group pattern up to La, when there is a switchback to Ac
• Sc-Y-Lu-Lr shows a TM switch back pattern
• La, and to lesser extent Ce are rather separated from the rest of the Ln, consistent with Restrepo and here.


• Sc and Lu are close to the amphoteric territory and are both in fact, weakly amphoteric
• The post-cerium Ln and An (but for Th) all fall within basic cation territory
• EA values for the An are estimates and need to be treated with due caution
• The light actinides (Th to Cm) occupy a tight locus, with the exception of Th, where the 5f collapse is thought to occur, and Pu, which sits on the border of 5f delocalisation and localisation
• While the light actinides U to Cm are shown as being cationic they are all known in amphoteric forms


• The heavy actinides, Bk to Lr, are widely dispersed
• All the Ln, bar Tm, are located within close proximity of the light An locus; Tm is the least abundant stable Ln
• The gap between La and Ce, and rest of the Ln is consistent with Restrepo's findings and here
• Nobelium in this edition of the chart falls off the bottom, having a radius 1.58 (cf Es) and an EA of -2.33
• There is an extraordinary alignment between He and the Group 2 metals


• Magnesium is on the cationic-amphoteric boundary; some of its compounds show appreciable covalent character
• Li, being the least basic of the alkali metals, is located just outside the alkalic zone; Li compounds are known for their covalent properties
• The reversal of the positions of Fr and Cs is consistent with Cs being the most electronegative metal
• A similar, weaker pattern is seen with Ba and Ra.

Conclusion
So there it is, just two properties account for nearly everything.

Click images below to enlarge:



Top of Page

---

Year:  2020

PT id = 1122, Type = formulation data

Vernon's Constellation of Electronegativity

René Vernon has created a "Constellation of Electronegativity" by plotting Electronegativity against Elemental Orbital Radii (r_orb)

Observations on the EN plot:

1. The results are similar to the orbital radii x EA plot, although not quite as clear, including being more crowded
2. Very good correspondence with natural categories
3. Largely linear trends seen along groups 1-2, 17 and 15-18 (Ne-Rn)
4. First row anomaly seen for He (or maybe not since it lines up with the rest of group 2)
5. For group 13, the whole group is anomalous
6. For group 14 , the whole group is anomalous no doubt due to the scandide contraction impacting Ge and the double whammy of the lanthanide and 5d contraction impacting Pb
7. F and O are the most corrosive of the corrosive nonmetals
8. The rest of the corrosive nonmetals (Cl, Br and I) are nicely aligned with F
9. The intermediate nonmetals (IM) occupy a trapezium
10. Iodine almost falls into the IM trapezium
11. The metalloids occupy a diamond, along with Hg; Po is just inside; At a little outside
12. Rn is metallic enough to show cationic behaviour and falls into the metalloid diamond
13. Pd is located among the nonmetals
14. The proximity of H to Pd is again (coincidentally?) curious given the latter's capacity to adsorb the former
15. The post-transition metals occupy a narrow strip overlapping the base of the refractory metal parallelogram
16. Curiously, Zn, Cd, and Hg (a bit stand-off-ish) are collocated with Be, and relatively distant from the PTM and the TM proper
17. The ostensibly noble metals occupy an oval; curiously, W is found here; Ag is anomalous given its greater reactivity; Cu, as a coinage metal, is a little further away
18. Au and Pt are nearest to the halogen line
19. The ferromagnetic metals (Fe-Co-Ni) are colocated
20. The refractory metals, Nb, Ta, Mo, W and Re are in a parallelogram, along with Cr and V; Tc is included here too
21. Indium is the central element of the periodic table in terms of mean orbital radius and EN; Tc is next as per the EA chart
22. The reversal of He compared to the rest of the NG reflects #24
23. All of the Ln and An fall into an oval of basicity, bar Lr
24. The reversal of the positions of Fr and Cs is consistent with Cs being the most electronegative metal
25. A similar, weaker pattern is seen with Ba and Ra.

Click to enlarge:


Top of Page

---

Year:  2020

PT id = 1147, Type = formulation

Periodic Ziggurat of The Elements

By René Vernon, the Periodic Ziggurat of the Elements. Click to enlarge:



Top of Page

---

Year:  2020

PT id = 1157, Type = data

Molar Magnetic Susceptibilities, Periodic Table of

Periodic Table of Molar Magnetic Susceptibilities by René Vernon, who writes:

I had read that the lanthanides were characterised by their magnetic properties, but never fully appreciated what this means. To this end, here is a table of Molar Magnetic Susceptibility (MMS) values (χ) for the elements, where MMS is a measure of how much a material will become magnetised in an applied magnetic field.

Formally, MMS is the ratio of magnetisation M (magnetic moment per unit volume) to the applied magnetising field of intensity H, allowing a simple classification into two categories of most materials responses to an applied magnetic field:

Alignment with the magnetic field, χ > 0, gives rise to paramagnetism
Alignment against the magnetic field, &chi; < 0, gives rise to diamagnetism

Six observations:

1. The average value for each block is:

• s 20
• p –35
• d 125
• 4f 46,000
• 5f 522

2. Lanthanides having unpaired 4f metals (Ce to Tm) have magnetic susceptibilities two to four orders of magnitude larger than those of "normal" metals.

3. Mn (511), Pd (540), O (3415) [this is actually the triplet diradical molecule O₂] & Bi (-280) stand out. [A magnetic cross would be good for repelling a bismuth vampire.]

4. MMS reduces going down all groups of the d-block. The average reduction going from 4d to 5d is 50%.

5. In group 3 there is a reduction of 48% on going from Y to La. If Lu is instead placed under Y the reduction is 2%.

6. There are at least six, rather than three, ferromagnetic metals.


Top of Page

---

Year:  2020

PT id = 1161, Type = formulation

Vernon's Periodic Treehouse

René Vernon's Periodic Treehouse of the Elements, fearuring the World's longest dividing line between metals and nonmetals.

René writes:

I can't remember what started me off on this one. It may have been Mendeleev's line, as shown on the cover of Bent's 2006 book, New ideas in chemistry from fresh energy for the periodic law.

There are a few things that look somewhat arbitrary, so I may revisit these:

• Ce is known at +4, Pr is known as +5, and I recall seeing some speculation about the possibility of Nd +6. (Pm +7 may be overreach.)
• Tl is lined up under Au even though Tl prefers +1. That said Au is not adverse to +1.
• I stopped at Hs since the limits of SHE chemistry just about runs out there.
• The dividing line between metals and nonmetals is 73 element box sides long.

Click to enlarge:



Top of Page

---

Year:  2020

PT id = 1165, Type = formulation

Vernon's (Partially Disordered) 15 Column Periodic Table

A formulation by René Vernon, who writes:

"Here is a 15-column table which is a hybrid of a Mendeleev 8-column table and an 18-column standard table. The key relocations are the p-block nonmetals to the far left; and the coinage and post-transition metals under their s and early d-block counterparts.

"Taking a leaf out of Mendeleev's playbook, I ignored atomic number order when this seemed appropriate. It's refreshing to see the traditional horizontal gaps between blocks disappear. (DIM did not like these.)

"Since Dias (2004, see references below) reckoned a periodic table is a partially ordered set forming a two-dimensional array, I believe I now have a partially ordered table that is partially disordered twice over.

"The table has some curious relationships. Equally, some relationships seen in the standard form are absent. The Group 2, 3, and aluminium dilemmas disappear. This confirms my impression that such dilemmas have no intrinsic meaning. Rather, their appearance or non-appearance is context dependent."

Notes & references below.



Groups 1 to 4 have either a C or F suffix where C (nonmetal) is after the importance of carbon to our existence; and F (metal) is for the importance of iron to civilisation.

Groups 1C and 1F present the greatest contrast in nonmetallic and metallic behaviour.

Coactive Nonmetals: They are capable of forming septenary heterogeneous compounds such as C₂₀H₂₆N₄O₁₀PSSe.

Group 2C: Helium is shaded as a noble gas. "Heliox" is a breathing gas mixture of helium and oxygen used in saturation diving, and as a medical treatment for patients with difficulty breathing.

Group 3C: Boron over nitrogen looks odd. Yet one boron atom and one nitrogen atom have the same number of electrons between them as two adjacent carbon atoms. The combination of nitrogen and boron has some unusual features that are hard to match in any other pair of elements (Niedenzu & Dawson 1965).

Boron and phosphorus form a range of ring and cage compounds having novel structural and electronic properties (Paine et al. 2005).

Metalloids. I treat them here as nonmetals given their chemistry is predominately that of chemically weak nonmetals.

Metals: The labels electropositive; transition; and electronegative are adapted from Kornilov (2008).

Group 1F: Monovalent thallium salts resemble those of silver and the alkali metals.

An alloy of cesium (73.71%), potassium (22.14%) and sodium (4.14%) has a melting point of –78.2°C (–108.76°F) (Oshe 1985).

Silver, copper, and gold, as well as being the coinage metals, are borderline post-transition metals.

Group 2F: Beryllium and magnesium are not in fact alkaline earths. Beryllium is amphoteric rather than alkaline; magnesium was isolated in impure form from its oxides, unlike the true alkaline earths. The old ambiguity over whether beryllium and magnesium should go over calcium or zinc has gone.

Nobelium is here since +2 is its preferred oxidation state, unlike other actinoids.

Group 3F: Aluminium is here in light of its similarity to scandium (Habishi 2010).

InGaAsP is a semiconducting alloy of gallium arsenide and indium phosphide, used in lasers and photonics.

There is no Group 3 "issue" since lanthanum, actinium, lutetium and lawrencium are in the same family.

Gold and aluminium form an interesting set of intermetallic compounds known as Au₅Al₂ (white plague) and AuAl₂ (purple plague). Blue gold is an alloy of gold and either gallium or indium.

Lanthanoids: The oxidation state analogies with the transition metals stop after praseodymium. That is why the rest of lanthanoids are footnoted in dash-dot boxes.

Actinoids: The resemblance to their transition metal analogues falters after uranium, and peters out after plutonium.

Group 4F: It's funny to see titanium—the lightweight super-metal—in the same group as lead, the traditional "heavy" metal.

This is the first group impacted by the lanthanoid contraction (cerium through lutetium) which results in the atomic radius of hafnium being almost the same as that of zirconium. Hence "the twins".

The chemistry of titanium is significantly different from that of zirconium and hafnium (Fernelius 1982).

Lead zirconate titanate Pb[Zr_xTi_1–x]O₃ (0 ≤ x ≤ 1) is one of the most commonly used piezo ceramics.

Group 5: Bismuth vanadate BiVO₄ is a bright yellow solid widely used as a visible light photo-catalyst and dye.

Steel Friends: The name is reference to their use in steel alloys. They have isoelectronic soluble oxidizing tetroxoanions, plus a stable +3 oxidation state. (Rayner-Canham 2020).

Ferromagnetic Metals: The horizontal similarities among this triad of elements (as is the case among the PGM hexad) are greater than anywhere in the periodic table except among the lanthanides (Lee 1996). The +2 aqueous ion is a major component of their simple chemistry (Rayner-Canham 2020).

Group 8: "Rubiferous metals" (classical Latin rubēre to be red; -fer producing) is from the reddish-brown colour of rust; the most prevalent ruthenium precursor being ruthenium trichloride, a red solid that is poorly defined chemically but versatile synthetically; and the red osmates [OsO₄(OH)₄]^?2 formed upon reaction by osmium tetroxide with a base.

Group 9: "Weather metals" comes from the use of cobalt chloride as a humidity indicator in weather instruments; rhodium plating used to "protect other more vulnerable metals against weather exposure as well as against concentrated acids or acids fumes" (Küpfer 1954); and the "rainbow" etymology of iridium.

Group 10: "Catalytic metals" is after a passage in Greenwood and Earnshaw, "They are... readily obtained in finely divided forms which are catalytically very active." (2002). Of course, many transition metals have catalytic properties. That said, if you asked me about transition metal catalysts, palladium and platinum would be the first to come to mind. Group 10 appear to be particularly catalytic.

References:

• Dias JR 2004, "The periodic table set as a unifying concept in going from benzenoid hydrocarbons to fullerene carbons", in DH Rouvray & RB King (eds.), The periodic table: into the 21st century, Institute of Physics Publishing, Philadelphia, pp. 371–396 (375)
• Fernelius WC 1982, "Hafnium," J. Chem. Educ. vol. 59, no. 3, p. 242
• Greenwood NN & Earnshaw A 2002, Chemistry of the elements, 2nd ed., Butterworth-Heinemann, Oxford, p. 1148
• Habashi F 2010, "Metals: typical and less typical, transition and inner transition", Foundations of Chemistry, vol. 12, pp. 31–39
• Lee JD 1996, Concise inorganic chemistry, 5th ed., Blackwell Science, Oxford, p. 753
• Kornilov II 1965, "Recent developments in metal chemistry", Russian Chemical Reviews, vol. 34, no. 1, p. 33
• Küpfer YJ 1954, "Rhodium uses in plating", Microtecnic, Agifa S.A., p. 294 Niedenzu K & Dawson JW 1965, Boron-nitrogen compounds, Springer, Berlin, preface
• Oshe RW (ed.) 1985, "Handbook of thermodynamic and transport properties of alkali metals", Blackwell Scientific, Oxford, p. 987
• Paine et al. 2005, "Recent developments in boron-phosphorus ring and cage chemistry", in Modern aspects of main group chemistry, M Lattman et al. (eds.), ACS Symposium Series, American Chemical Society, Washington DC, p. 163
• Rayner-Canham G 2020, The periodic table: Past, present, and future, World Scientific, Singapore
Top of Page

---

Year:  2020

PT id = 1168, Type = formulation

Shukarev's Periodic System (redrawn by Vernon)

Shukarev SA 1975, "On the image of the periodic system with the use of fifth move of late a-elements", Collection of Scientific and Methodological Articles on Chemistry. M.: Higher School, no 4, pp 3-12 (in Russian). Redrawn and commented upon by René Vernon:



Top of Page

---

Year:  2020

PT id = 1170, Type = formulation

Zig-Zag Line, Periodic Table

Periodic Table showing the (regular) zig-zag line by René Vernon who writes:

"It is curious that the full extent of the line has never been properly mapped (to my knowledge).

"Elements on the downside of the line generally display increasing metallic behaviour; elements on the topside generally display increasing nonmetallic behaviour.

"When you see the line you will usually see only about a quarter of it. The line actually runs all the way across the periodic table, as shown, for a total of 44 element box sides.

"Interpretations vary as to where the line runs. None of these is better than any other of them, provided the interpretation is explained to you. The thick black line (at least in the p-block) is the most common version. The metalloids tend to lie to either side of it.

"Polonium and astatine are shown here as post-transition metals although either or both of them are sometimes shown as metalloids (or, in the case of astatine, as a halogen). Polonium conducts electricity like a metal and forms a cation in aqueous solution. In 2013, astatine was predicted to be a centred cubic-metal Condensed Astatine: Monatomic and Metallic This prediction has been cited 35 times, with no dissenters. Astatine also forms a cation in aqueous solution. Oganesson is shown as having (as yet) unknown properties.

"The dashed lines show some alternative paths for the zigzag line.

"The lower one treats the metalloids as nonmetals since metalloid chemistry is predominately nonmetallic. The lower line and the upper line are sometimes shown together used when the metalloids are treated as neither metals nor nonmetals."



And in Janet Left-Step form:


Top of Page

---

Year:  2020

PT id = 1171, Type = data formulation

16 Dividing Lines Within The Periodic Table

René Vernon points out that there are 16 dividing lines within the periodic table.

A-Z Dividing Lines:

48-crash line: Named after the dramatic reduction in physical metallic character after group 11, Cd being Z = 48. Group 12 show few transition metal attributes and behave predominantly like post-transition metals.

Big bang line: H makes up about 73% of the visible universe.

Corrosive line: O, F, Cl = most corrosive nonmetals.

d-Block fault line: Group 3 show little d-block behaviour; group 4 is the first in which characteristic d-block behaviour occurs.

Deming line: Demarcates the metalloids from the pre-halogen nonmetals. The "reactive" nonmetals to the right of the metalloids each have a sub-metallic appearance (C, O, Se, I).

Edge of the world line: No guesses for this one.

Klemm line: Klemm, in 1929, was the first to note the double periodicity of the lanthanides (Ce to Lu). Lockyer line: After the discoverer of He, the first element not found on Earth.

Ørsted line: After the magnetic effects believed to be responsible for Mn having a crystalline structure analogous to white P; Tc: First radioactive metal; Re: Last of the refractory metals; "most radioactive" of the naturally occurring elements with stable isotopes. Fe: First of the ferromagnetic metals; Ru: First noble metal; Os: Densest of naturally occurring metals. The number of unpaired d electrons peaks in group 7 and reduces thereafter.

Platypus line: Tl shows similarities to Rb, Ag, Hg, Pb.

Poor metal line: Most metals (80%) have a packing factor (PF)³ 68%. Ga: Has a crystalline structure analogous to that of iodine. BCN 1+6.* PF 39.1%. Melts in your hand. In: Partly distorted structure due to incompletely ionised atoms. BCN 4+8. PE 68.6%. Oxides in preferred +3 state are weakly amphoteric; forms anionic indates in strongly basic solutions. Tendency to form covalent compounds is one of the more important properties influencing its electro-chemical behaviour. Sn: Irregularly coordinated structure associated with incompletely ionised atoms. BCN 4+2. PF 53.5%. Oxides in preferred +2 state are amphoteric; forms stannites in strongly basic solutions. Grey Sn is electronically a zero band gap semimetal, although it behaves like a semiconductor. Diamond structure. BCN 4. PF 34.0%. Pb: Close-packed, but abnormally large inter-atomic distance due to partial ionisation of Pb atoms. BCN 12. PF 74%. Oxide in preferred +2 state is amphoteric; forms anionic plumbates in strongly basic solutions. Bi: Electronic structure of a semimetal. Open-packed structure (3+3) with bonding intermediate between metallic and covalent. PF 44.6%. Trioxide is predominantly basic but will act as a weak acid in warm, very concentrated KOH. Can be fused with KOH in air, resulting in a brown mass of potassium bismuthate.

Seaborg line: No f electrons in gas phase La, Ac and Th atoms.

Triple line: N = gas; S = solid; Br = liquid.

Zigzag lobby: H needs no intro. Li: Many salts have a high degree of covalency. Small size frequently confers special properties on its compounds and for this reason is sometimes termed 'anomalous'. E.g. miscible with Na only above 380° immiscible with molten K, Rb, Cs, whereas all other pairs of AM are miscible with each other in all proportions. Be: Has a covalent component to its otherwise predominately metallic structure = low ductility. Lowest known Poisson's ratio of elemental metals. Amphoteric; predominately covalent chemistry atypical of group 2. Some aspects of its chemical properties are more like those of a metalloid.

Zigzag line: Eponymous metal-nonmetal dividing line.

Zintl line: Hypothetical boundary highlighting tendency for group 13 metals to form phases with a various stoichiometries, in contrast to group 14+ that tend to form salts with polymeric anions.

* BCN = bulk coordination number


Top of Page

---

Year:  2020

PT id = 1174, Type = formulation

Split s-, p- & d-Block Periodic Table

René Vernon presents a periodic table formulation with split s-, p- & d-blocks.

• The traditional form of periodic table is a hybrid of an electronic and a chemistry based table.
• An electronic or physics-based table would show (a) He over Be; and (b) group 3 as Sc-Y-Lu-Lr; and (c) group 13 as B-Al-Ga-In-Tl
• A chemistry-based table would show (d) He over Ne; and (e) B-Al over Sc-Y-La-Ac.
• What we have instead is a hybrid table with 1(c) and 2(d). It is not as symmetric or tidy as the pure Lu form; neither is it as irregular as the form with three split blocks.

The details: Group 3 as B-Al-Ga-In-Tl

Al over Sc has some history, which seems to have been forgotten.

Here are some other tables with B-Al-Sc-Y-La:

• Rang (1893)
• Gooch & Walker (1905)
• Cuthbertson & Metcalfe (1907)
• Baur (1911)
• Rydberg (1913)
• Black & Conant (1920)
• Lewis (1923)
• Hubbard (1924)
• Deming's table (1925), which popularised the medium-long form
• Antropoff (1926)
• LeRoy's table (1927)
• Irwin (1939)
• Seaborg (1945), with B left in group 13
• Yost & Russell (1946)
• Coryell (1952)
• Pauling's table (1960)
• Habishi's Metallurgist's Periodic Table (1992), Habishi leaves B in group 13

What was it that these luminaries knew about B-Al-Sc-Y-La-Ac that is deemed to be no longer relevant, and why is that the case?

Deming (1947, Fundamental Chemistry, 2nd ed. p. 617) located Al with the pre-transition metals in groups 1?2. Cox (2004, Inorganic Chemistry, 2nd ed. p. 185) refers to the pre-transition metals as those in groups 1 and 2, and Al. Here's that 2019 periodic table (by me), recording oxidation number trends, further suggesting B and Al are better placed over Sc.

In this vein, Rayner-Canham (2020, The periodic table: Past, present, and future, pp. 178–181) writes:

"It was Rang in 1893 who seems to have been the first, on the basis of chemical similarity, to place boron and aluminum in Group 3.

"Such an assignment seems to have been forgotten until more recent times. Greenwood and Earnshaw have discussed the way in which aluminum can be considered as belonging to Group 3 as much as to Group 13 particularly in its physical properties. Habashi has suggested that there are so many similarities between aluminum and scandium that aluminum's place in the Periodic Table should actually be shifted to Group 3.

"In terms of the electron configuration of the tripositive ions, one would indeed expect that Al³⁺ (electron configuration, [Ne]) would resemble Sc³⁺ (electron configuration, [Ar]) more than Ga³⁺ (electron configuration, [Ar]3d10). Also of note, the standard reduction potential for aluminum fits better with those of the Group 3 elements than the Group 13 elements (Table 9.2) – as does its melting point.

"In terms of their comparative solution behavior, aluminum resembles both scandium(III) and gallium(III). For each ion, the free hydrated cation exists only in acidic solution. On addition of hydroxide ion to the respective cation, the hydroxides are produced as gelatinous precipitates. Each of the hydroxides redissolve in excess base to give an anionic hydroxo-complex, [M(OH)₄]^–... There does seem to be a triangular relationship between these three elements. However, aluminum does more closely resemble scandium rather than gallium in its chemistry. If hydrogen sulfide is bubbled through a solution of the respective cation, scandium ion gives a precipitate of scandium hydroxide, and aluminum ion gives a corresponding precipitate of aluminum hydroxide. By contrast, gallium ion gives a precipitate of gallium(III) sulfide. Also, scandium and aluminum both form carbides, while gallium does not."

To answer my own question as to why group 3 as B-Al-Sc-Y-La-Ac has been forgotten.

I suspect what happened is that it was historically known that group 3 was better represented as B-Al-Sc-Y-La-[Ac]. Then, with the advent and rise of modern electronic structure theory, B-Al- got moved to the p-block because, after all, they were p-block elements, never mind the damned chemistry. And La stayed in the d-block since it was the first element to show 5d electron, and 4f did not show until Ce. And Lu stayed where it was since even thought it was learnt that the f shell become full at Yb, rather than Lu, nothing changed about the chemistry of Lu. Nowadays, this has all been forgotten.

The modern periodic table is a chemistry-physics hybrid.

Lu in group 3 demands He over Be. La in group 3 demands B-Al over Sc. Neither option gets up. The more important consideration is to teach the history and have students and chemists appreciate both perspectives.



Top of Page

---

Year:  2021

PT id = 1181, Type = formulation review

Understanding Periodic and Non-periodic Chemistry in Periodic Tables

Cao C, Vernon RE, Schwarz WHE and Li J (2021). Front. Chem. 8:813. https://doi.org/10.3389/fchem.2020.00813

Abstract:

The chemical elements are the "conserved principles" or "kernels" of chemistry that are retained when substances are altered. Comprehensive overviews of the chemistry of the elements and their compounds are needed in chemical science. To this end, a graphical display of the chemical properties of the elements, in the form of a Periodic Table, is the helpful tool. Such tables have been designed with the aim of either classifying real chemical substances or emphasizing formal and aesthetic concepts. Simplified, artistic, or economic tables are relevant to educational and cultural fields, while practicing chemists profit more from "chemical tables of chemical elements."

Such tables should incorporate four aspects:

(i) typical valence electron configurations of bonded atoms in chemical compounds (instead of the common but chemically atypical ground states of free atoms in physical vacuum);

(ii) at least three basic chemical properties (valence number, size, and energy of the valence shells), their joint variation across the elements showing principal and secondary periodicity;

(iii) elements in which the (sp)8, (d)10, and (f)14 valence shells become closed and inert under ambient chemical conditions, thereby determining the "fix-points" of chemical periodicity;

(iv) peculiar elements at the top and at the bottom of the Periodic Table.

While it is essential that Periodic Tables display important trends in element chemistry we need to keep our eyes open for unexpected chemical behavior in ambient, near ambient, or unusual conditions. The combination of experimental data and theoretical insight supports a more nuanced understanding of complex periodic trends and non-periodic phenomena.




Thanks to René Vernon for the tip.

Top of Page

---

Year:  2021

PT id = 1183, Type = formulation data

Crustal Abundance vs. Electronegativity

A chart by René Vernon of Elemental Abundance (g/kg log₁₀) vs. Electronegativity, H to Bi.

René writes:

Below is a remarkable XY chart where x = electronegativity and y = crustal abundance (log₁₀). It stops at the end of the s-process, at Bi. The abundance figures are from the CRC Hanbook of Physics and Chemistry (2016-2017).

I say remarkable as I had little idea what the chart would end up looking like when I started plotting the values.

As well as its coloured regions, I've marked out track lines for six of the main groups and one for group 3.

Observations

The rose-coloured arc on the left encompasses the pre-transition metals i.e. the alkali and alkaline earth metals and aluminium, followed by, in the orange rectangle, the rare earth metals. Opposite these regions, along the southern boundary of the green paddock, are the halogens.

In the pale yellow field sheltered by the pre-transition metals and the REM, are the 3d transition metals and, in the white corral, are 4d and 5d base transition metals. Opposite these regions, in the green paddock, are the core nonmetals H, C, N, O, P and S, with Se as an outlier.

Following in the grey blob are the post-transtion or poor metals, immediately adjacent to the bulk of the metalloids or poor nonmetals.

Finally, in the light blue patch, the noble metals are complemented by the noble gases frolicking in the open.

Abundance tends to decrease with increasing Z. Notable exceptions are Li, B, N and Si.

Curiosities

• H and P are almost on top of one another
• The proximity of Be to the post-transition metals, and its relative scarcity in the crust
• The metalloids, with their intermediate values of electronegativity, go down the middle. At the same time they span nearly the full range of abundance.
• B-Ga-Sc-Y-La are in a row
• N falls along the halogen line
• The abundance of O and Si, which we see in the form of silica
• F is more abundant in the crust than 85 percent of metals
• Al is the most abundant metal. Al and Fe are in the same vicinity: "Curiously, the chemistry of aluminium also resembles that of the iron(III) ion... These similarities may be ascribed to the same 3+ charge and near-identical ion radii (and hence charge density)." (Rayner-Canham 2020, p. 191)
• The abundance of Ar compared to the rest of the noble gases. Apparently this is influenced by the radioactive decay of potassium-40 in Earth's core, which is considered one of the main sources of heat powering the geodynamo that generates Earth's magnetic field. It has been suggested that a large amount of Ar may be present in the core, as the compound ArNi with an L11 Laves structure (similar to an intermetallic phase, and related to a cubic close packed lattice). ArNi is stabilised by notable electron transfer from Ni to Ar, changing their electron configurations toward 3d⁷ and 4s¹. (Adeleke et al. 2019)
• Ti, a light yet strong metal, is about 2,500 times as abundant as Sn, a weak heavy metal
• Zn is an outlaw post-transition metal
• The most active 4d-5d transition metals (Zr, Hf) occupy a boundary overlap with the rare earth metals
• Ag, which has a largely main-group chemistry, is located in the PTM region. It is about 20 times as abundant as the noble meals
• Re is an outlaw noble metal

Comment

I was intrigued by the article referring to Ni and Ar, and the suggestion of Ar becoming somewhat anionic, albeit in extreme conditions (140 GPa, 1500 K)

References

• Adeleke AA, Kunz M, Greenberg E, Prakapenka VB, Yao Y, Stavrou R 2019, A high-pressure compound of argon and nickel: Noble gas in the Earth's core?, ACS Earth and Space Chemistry, vol. 3 no. 11, pp. 2517-2544, https://pubs.acs.org/doi/10.1021/acsearthspacechem.9b00212
• Rayner-Canham G, 2020, The periodic table: Past, present, future, World Scientific, Singapore

Correlations

I wasn't looking for these but they at least exist as follows:

• Metals with lower EN, i.e. < 1.7, or active nonmetals with higher EN, tend to be concentrated in silicate or oxide phases that are more easily found in the crust due to their lower density, and hence have higher abundances.
• Metals with moderate EN 1.7 to 2.1, say the later transition metals and post-transition metals, tend to form sulfide liquid phases; are less easily found in the crust due to their relatively higher densities; and are less abundant by about two orders of magnitude compared to the metals found in silicate or oxide phases.
• Metals with EN > 2.2, i.e. the noble metals, have an affinity for a metallic liquid phase, and are depleted in the crust since they generally sank to the core and hence have very low abundances. They are about two orders of magnitude less abundant than the sulfide metals.

My references are:

• Cox PA 1997, The elements: Their origin, abundance and distribution;
• Gill R 2014, Chemical fundamentals of geology and environmental geoscience;
• White WA 2020, Geochemistry

Thus the abundance of the metals in the crust tends to fall with increasing EN.

• For the nonmetals, the relative average abundance proportions are about 5: 700: 250: 1 for, respectively, the metalloids; the core nonmetals H, C, N, P, S, and Se; the halogen nonmetals; and the noble gases. Si and O were left out as outliers, in terms of their massive abundances.
• Thus, metalloids aside, the abundance of the nonmetals tends to fall with increasing EN. I don't know what's going on with the metalloids.
• The chart may prompt some further appreciative enquiry:
• In the case of exceptions to the initial three generalisations why do these occur?
• Why is Li so rare, compared to the other alkali metals?
• Why is Si good at forming a planetary crust?

An answer from L. Bruce Railsback, creator of the Earth Scientist's Periodic Table https://www.meta-synthesis.com/webbook/35_pt/pt_database.php?PT_id=142:

"I think I can answer one of the questions. 'Why is Si good at forming a planetary crust?' – because it's so bad at staying in the core. Silicon isn't sufficiently metallic to stay in the core. Even in the mantle and crust, it doesn't go into non-metal solids well: in cooling magmas, it's only a lesser member of the early-forming minerals (e.g., Mg₂SiO₄, forsterite, where it's outnumbered two to one). The mineral only of Si as a cation, SiO₂ (quartz), is the LAST mineral to form as a magma cools, in essence the residuum of mineral-forming processes. At least some this thinking is at Bowen's Reaction Series and Igneous Rocks at http://railsback.org/FundamentalsIndex.html#Bowen"

• Why do the metalloids span such a wide range of abundances?
• If H is supposed to make up ca. 74% of the universe why does it have the same abundance in the Earth's crust as P?
• In what form is H found in Earth's crust—water, hydroxides?
• If H is supposed to make up ~ 74% of the universe why does it have the same abundance in the Earth's crust as P?
• Are there any chemical similarities between H and P, given both have some metalloidal character? The have virtually identically electron affinities. H is sometimes positioned above B due to chemical similarities. It then forms a diagonal relationship with C, which in turn has a diagonal relationship with P, which has a diagonal relationship with Se e.g. P reacts with Se to form a large number of compounds characterised by structural analogies derived from the white phosphorus P4 tetrahedron.
• The rare earth metals are relatively rare, having an average abundance of 1% that of the 3d metals. That being so, why is their rareness sometimes questioned? Why does the crustal abundance of the REM plummet by two orders of magnitude towards the end of the lanthanides?

Which Electronegativity Scale?

The wide variety of methods for deriving electronegativities tend to give results similar to one another.

Click to enlarge:



Top of Page

---

Year:  2021

PT id = 1184, Type = formulation

van Spronsen's Periodic Table: Update

René Vernon writes:

I'd never before realised how clever van Spronsen's 1969 Periodic Table is. It seems to be the ultimate logical electronic version, informed by the actual filling sequence in the gas phase atoms, rather than the idealised sequence.

So, H-He are over Li-Be.

Group 3 is Sc-Y-La-Ac since that is where the d-shell starts filling. In the rest of the d-block, there are (4+1) x d5 and (4+2) x d10.

The f-block starts with Ce, as that is where the f-shell starts filling. Notice the high degree of regularity with the 4 x f7 and the 4 x f14, and how Th is treated i.e. as 5f0.

After DIM's 8-column form, I believe the periodic family tree now looks like this:

Three split-blocks
1a. He over Ne; B-Al over Sc-Y-La-Ac = old school form
1b. H-He over F-Ne; ditto = e.g. Soddy 1914?, Kipp 1942?

Two split blocks
2a. He over Ne; group 3 as Sc-Y-La-Ac = popular form

One split-block
3a. He over Ne; group 3 as Sc-Y-Lu-Lr = Lu form 3b. He over Be; group 3 as Sc-Y-La-La = forgotten van Spronsen form

No split blocks
4. He over Be = Janet equivalent



Top of Page

---

Year:  2021

PT id = 1190, Type = data

Electronegativity: A Three-Part Wave

René Vernon points out that although there is a general trend in increasing electnegativity from Cs to F, there is actually an s-curve in the data.

Electronegativity across groups 1 to 18 appears to a show a three-part wave-like pattern.

There is a rise from group 1 to group 6, followed by a fall at group 7. I guess for group 7 that the EN for Mn is based on +2 and in this state Mn has five 3d electrons. The EN for Tc and Re are presumably based on +7, in which they notionally have underlying [Kr] and [Xe] cores.

There is rise from 7 to 8 (why?); a mesa from 8 to 11 (why?) that includes the PGM; and a fall at group 12. The fall may be influenced by group 12 having a full d shell; ditto group 13.

There is a rise from 13 to 18. Whereas in group 13 there is ionic chemistry in the form of the cations of Al to Tl this is not the case for C, Si, and Ge in group 14. Sn is reluctant to form a cation expect at pH < 1, and there is no Pb⁴⁺ cation.

The R2 value of 0.9739 is a best fit value for a second order polynomial. R2 for a straight line is 0.786



Top of Page

---

Year:  2021

PT id = 1203, Type = formulation

Vernon's CSF Left-Step Periodic Table.

René Vernon's CSF Left-Step Periodic Table.

"I was prompted to switch to He-Be and [to develop a Janet type] left-step periodic table. I suggest it remediates concerns about H and He, and Lu in group 3.


Pros


• There is symmetry in this version.
• The physiochemical relationship of He to Ne is retained.

Cons

• There is a loss of physiochemical regularity in placing He over Be. Even if helium can be enticed to become chemically active, it will still be very much better located in group 18.
• While the d, p, and s blocks start with the appearance of the relevant electron, there is a loss of consistency with La at the start of the f-block. This is confusing to students since there is no such inconsistency in the La form.
• In terms of predominant differentiating electrons in each block, this form is less consistent than an La table.
• There is one less form of "element block-type" symmetry, than in the La form.

Click here to enlarge:


Top of Page

---

Year:  2021

PT id = 1210, Type = formulation data

Vernon's Eight-Fold Way Periodic Table

René Vernon suggests that the chemical elements can be grouped into eight classes: four metallic (Active, Transition, Post-Transition and Noble) and four non-metallic (Halogen, Biogen, Metalloid and Noble gas):



Top of Page

---

Year:  2021

PT id = 1244, Type = data

Vernon's ABC Periodic Table

The Annotated Blocks & Categories (ABC) Periodic Table by René Vernon.

Click image to enlarge:


Top of Page

---

Year:  2022

PT id = 1231, Type = formulation 3D

Kaleidocycle of the Periodic Table

Pablo Cassinello provides a "Three-dimensional figure to improve the didactics of the Periodic Table", a Kaleidocycle of the Periodic Table.

There is a full article about this dynamic, three dimensional formulation in Pablo's blog in Chem Ed Xchange, including instructions on how to make the object.

Pablo writes:

"A kaleidocycle has four different faces, each one made of a juxtaposition of rhombuses. By turning it you can easily choose one of the four faces. On these, four different pictures can be displayed. In this three-dimensional figure of the periodic table are the elements organized in four blocks according to their final electronic structure. It is intended that students with this playful figure actively participate in classes by rotating their kaleidocycle looking for the groups or elements that are being studied. The entire periodic table fits in one palm of their hands. It is also a didactic device because students only focus their attention on one block or group of elements from the entire Periodic Table. It can be a more entertaining, motivating and exciting way of learning about the subject of the Periodic Table."



Thanks to René for the tip!

Top of Page

---

Year:  2022

PT id = 1241, Type = data

Electronegativity Seamlessly Mapped Onto Various Formulations of The Periodic Table

A discussion on the Google Groups Periodic Table Discussion List, involving a René Vernon, Nawa Nagayasu & Julio Samanez (all contributors this database) lead to the development of the representations below, showing electronegativity seamlessly mapped onto a modified Left-Step Periodic Table:















Nawa Nagayasu has mapped electronegativity to Mendeleeve's formulation:



Nawa Nagayasu has mapped electronegativity onto other formulations, Julio's Binode Spiral:



Courtine's 1926 formulation:



and the "conventional", short, medium and long forms of the periodic table with hydrogen above and between B & C which show the botom-right-to-top-left electronegativity trend:



Jeff Moran's Spiral:



René Vernon's 777 Periodic Wedding Cake:



Valery Tsimmerman's ADOMAH formulation:



Valery Tsimmerman's ADOMAH tetrahedron (in a glass cube) formulation:




Top of Page

---

Year:  2022

PT id = 1252, Type = formulation

Vernon's Yin Yang of The Periodic Table

René Vernon writes:

"I was prompted to [develop] this item after reading Eric Scerri's open access article: In Praise of Triads. The nub of Eric’s article is to argue for the LST on the grounds of triad regularity, first-row-anomaly regularity, and consistency with QM.

"It occurs to me that efforts to introduce more regularity to the PT invariably introduce new irregularities elsewhere. For example, as far as triad regularity goes, the left step table (LST) with He over Be introduces its own anomaly in that no element in period 1 (H, He) is part of a triad whereas this is not the case for all periods thereafter. In contrast, all periods of the traditional table have at least one element that is part of a triad.

"As far as QM goes, this tells us that there is a theoretical regularity to the PT. This regularity can be used to inform e.g. the LST, ADOMAH or Julio’s binodes. But such depictions do not reflect the factual relationships we see amongst the chemistry of the elements as well as is the case for the conventional form. A most obvious example is that the LST, while being more consistent with QM, disrupts the bottom-left to top-right trend in metallic to nonmetallic character seen in conventional tables.

(I must caveat that I'm referring to the chemistry of the elements in conditions regularly occurring on Earth. For example, it has been reported that under sufficiently high pressures the elements change their EN and electron configurations. If so, this suggests a need for a different table at high pressure.)

At this point, the chemistry educators enter the picture. They move the s-block to left. Helium is relocated over Ne on the basis of its nobility. (This could change if a few compounds of He were to be synthesized). Somewhat similarly, La was discovered well before Lu, so it ended up under Y, and most folks see no good reason to replace La with Lu. Sure, in the 32-column form, the result is a split d-block but the infrequency with which the 32-column form appears is such that most people are not bothered. The result is the conventional table.

Philosophically, while the n+l based LST might represent the most general form of table, the conventional table appears to currently represent the most pragmatic derivation for chemists and chemistry educators.

Since the PT is classification rather than theory, and there will thus always be hard cases at the boundaries, there will invariably be minor variations in the depiction of the conventional table with respect to e.g. the placement of H, the composition of group 3, or the length of the f block.

And there will always be tables such as MR that focus on particular perspectives of relationships among the the elements.

I’ve tried to sketch what's going in the attached image:"

Click to enlarge.


Top of Page

---

Year:  2022

PT id = 1254, Type = formulation data

99 Elements Sorted by Density & Electronegativity

René Vernon writes:

"A little while I ago I noticed that a scatter plot of EN (revised Pauling) and density values of the elements resulted in a nice distribution, as per the table below.

"According to Hein and Arena (2013) nonmetals have low densities and relatively high EN values; the table bears this out. Nonmetallic elements occupy the top left quadrant, where densities are low and EN values are relatively high. The other three quadrants are occupied by metals. Of course, some authors further divide the elements into metals, metalloids, and nonmetals although Odberg argues that anything not a metal is, on categorisation grounds, a nonmetal.

Note 25 says:

(a) Weighable amounts of the extremely radioactive elements At (element 85), Fr (87), and elements with an atomic number higher than Es (99), have not been prepared.
(b) The density values used for At and Fr are theoretical estimates.
(c) Bjerrum (1936) classified "heavy metals" as those metals with densities above 7 g/cm^3.
(d) Vernon (2013) specified a minimum electronegativity of 1.9 for the metalloids.


• Bjerrum, N (1936). Bjerrum’s Inorganic Chemistry. London: Heinemann
• Hein, M; Arena, S (2013). Foundations of College Chemistry. Hoboken: John Wiley & Sons. pp. 226, G-6. ISBN 978-1-118-29823-7.
• Oderberg DS 2007, Real Essentialism, Routledge, New York, ISBN 978-1-134-34885-5
• Vernon R 2013, "Which elements are metalloids?", Journal of Chemical Education, vol. 90, no. 12, 1703?1707, doi:10.1021/ed3008457
Top of Page

---

Year:  2022

PT id = 1257, Type = formulation data

Tutti Frutti Periodic Table

René Vernon who writes:

"As a potentially powerful teaching and learning instrument: a Tutti Frutti periodic table. I feel younger folk [will] be delighted by it. The overlay of electron configurations and blocks was designed by a colleague of mine."

Click to enlarge:


Top of Page

---

Year:  2022

PT id = 1259, Type = formulation

Deming's 1923 Periodic Table, Updated by Vernon

René Vernon writes:

"Here is the 21st century version of Deming's 1923 formulation. Lacking elegance perhaps, but that’s messy chemistry for you. 25 columns wide rather than 18 or 32. Split s, p and d blocks. The connecting lines are based on four sources:

1. Deming
2. The literature since his time, as shown
3. The expected behaviour of the super-heavy elements
4. The smoothness of Z vs physiochemical property trendlines going down groups, for up to 40 physiochemical properties

"I used [the term] frontier metals to refer to the post-transition metals, since the latter term has never applied well to Al. The frontier adjective comes from a line by Russell and Lee in which they refer to Bi and Po occupying frontier territory on the PT, adjacent to the nonmetals (2006, p. 419).

"As far as metalloids are concerned, Dingle nicely summarized their status: "With ‘no-doubt' metals on the far left of the table, and no-doubt non-metals on the far right…the gap between the two extremes is bridged first by the poor (post-transition) metals, and then by the metalloids— which, perhaps by the same token, might collectively be renamed the 'poor non-metals'." (2017, p. 101)

Ref: Dingle 2017, The Elements: An Encyclopedic Tour of the Periodic Table, Quad Books, Brighton Russell AM & Lee KL 2005, Structure-Property Relations in Nonferrous Metals, John Wiley & Sons, Hoboken, NJ

Click to enlarge


Top of Page

---

Year:  2022

PT id = 1275, Type = formulation

777 Periodic Wedding Cake

René Vernon's version of Courtine’s flat projection (1926) of his periodic tower, the 777 Periodic Wedding Cake:


Top of Page

---

Year:  2022

PT id = 1276, Type = formulation data review

Periodic Table of Periodic Tables

René Vernon has collected the PT formulations in this PT database and classifed them as:

Short, Triangular, Medium, Long, Continious, Folding, Spatial & Unclassified

and tabulated them by date. The 'working document' is currently a word file.


Top of Page

---

Year:  2023

PT id = 1288, Type = formulation data

Holistic View of Metals & Nonmetals: Exploded View

From Organising the metals and nonmetals: An update by René Vernon from the chemrxiv preprint server.

Rene writes:

Abstract: This paper updates my 2020 article, Organising the metals and nonmetals in which I advocated for parsing the periodic table into four kinds of metals and four of nonmetals. This framework is retained and updated, and augmented with some additional chemistry-related and philosophical observations.


Top of Page

---

Year:  2024

PT id = 1299, Type = misc data

Can I Lick It? Periodic Table

From Reddit, a "A cool guide to element lickability".

Mark Leach writes:

"I think I would colour calcium yellow as it bubbles hydrogen gas when added to water."



Thanks to René Vernon for the tip!

Top of Page

---

Year:  2024

PT id = 1303, Type = formulation

Bilateral Symmetry in the Periodic Binodic Table

René Vernon, who developed these ideas, writes:

This table is adapted from the work of Gutiérrez-Samanez (2020), who discusses mathematising the chemical periodic system as a grid, which leads to a quadratic function or “binódica function” formed by pairs of periods or binodos (dyads).

The difference is that whereas Gutiérrez-Samanez showed the first pair of periods as H-He and Li-Be, this table shows the first period as e-n and H-He. Here, e is the electron and n is the neutron. Each pair of periods is shown pancake style rather than in a single row. The formula for the length of each paired period or binode is 2n² = 2, 8, 16, 32.

The idea of paired periods has a long history; it seems to have originated with Werner in 1905.

According to Jensen:

"The temptation to read more into the shape of the table than is really there is almost overwhelming. Even someone as great as Werner was tempted (1905). Having postulated a missing element between H and He, he decided to perfect the symmetry of his table by guaranteeing that rows of differing length always occurred in pairs. Consequently, he further postulated a row of three missing elements lying above the H-X-He row."

Rydberg (1913, pp. 12–13) used a formula 4n^2 for the number of elements in the paired periods: 4, 16, 32, 64. This formula is also used by Gutiérrez-Samanez.

Paired periods were also used by Janet (1928), Saz (1931), Achimov (1946) and Baca Mendoza (1953).

References

• Achimov EI 1946, Zhur. Obshchei Khim., vol. 16, p. 961; https://www.meta-synthesis.com/webbook/35_pt/pt_database.php?PT_id=776
• Baca Mendoza O 1953, Leyes Genéticas de los elementos Químicos, Nuevo Sistema Periódico, National University of Cusco, https://www.meta-synthesis.com/webbook/35_pt/Mendoza_PT.pdf, accessed May 12, 2024
• Gutiérrez-Samanez JA 2020, Binódic periodic system: a mathematical approach, Found Chem, vol. 22, pp. 235–266 (255)
• Janet C1928, Essais de classification hélicoïdale des éléments chimiques. Imprimerie Départementale de l’Oise, Beauvais, https://www.meta-synthesis.com/webbook/35_pt/pt_database.php?PT_id=152
• Jensen WB 1986, Classification, symmetry and the periodic table, Computers & Mathematics with Applications, vol. 12B, no. 12, pp. 487–510 (508)
• Rydberg JR 1913, Untersuchungen über das system der grundstoffe, Lunds Univ. Ärsskrift, vol. 9, no. 18. In French: 1914, Recherches sur le système des éléments, Journal de Chimie Physique, vol. 12, p. 585
• Saz E 1931, Iberica, vol. 35, p. 186
• Wemer A 1905, Beitrag zum Aufbau des periodischen Systems, Ber. Deut. Chem. Ges, vol. 38, pp. 914–921, 2022–2027


Top of Page

---

Year:  2024

PT id = 1315, Type = formulation 3D spiral

Dufour’s Elementree in 2D by Vernon

A 2 dimension (flat) drawing of Dufour’s 3 dimensional Elementree by René Vernon.

René Vernon writes:

"I was surprised by its lack of symmetry in Dufour’s Elementree, caused by the awkward placement of He, and the assignment of H as floating above Li and Be. Hydrogen is as much subject to the periodic law as any other element. Without aligning H over Li, and He over Be, I am not sure that Elementree can be made symmetrical."


Top of Page

---

Year:  2024

PT id = 1319, Type = misc

Elements of Fire & Light

René Vernon presents Elements of Fire and Light: The Majesty of The Periodic Table



Top of Page

---

What is the Periodic Table Showing?

Periodicity

© Mark R. Leach Ph.D. 1999 –

---

Queries, Suggestions, Bugs, Errors, Typos...

If you have any:

Queries
Comments
Suggestions
Suggestions for links
Bug, typo or grammatical error reports about this page,

please contact Mark R. Leach, the author, using mark@meta-synthesis.com

This free, open access web book is an ongoing project and your input is appreciated.

---
